- 184 -
1 Press Wi-Fi button on this unit and touch [Wi-Fi Setup].
2 Touch [Wi-Fi Setup Wizard].
3 Touch [YES].
4 Touch [QR code] or [Wi-Fi].
When [QR code] is selected
1 Start up the smartphone application “Image App”.
2 On the smartphone, select [QR code], and scan the QR code displayed on the
screen of this unit.
≥ The setup screen is displayed on the smartphone.
≥ When using an iOS device, perform the following operations:
1 Select the option that allows you to install the app on the profile screen of the “Image App”, and
follow the on-screen instructions to complete the installation.
2 Press the home button to close the displayed screen.
3 Touch [NEXT] on the screen of this unit to display its SSID.
4 After selecting the network name (SSID) of this unit from the Wi-Fi setup of the smartphone,
start up “Image App”.
3 Follow the on-screen instructions of the smartphone to set up a connection.
≥ When the settings is complete, the smartphone and this unit are connected directly, allowing you
to use remote operations. (l 154)
When [Wi-Fi] is selected
≥ If you are using an Android device, start up the smartphone application “Image App”.
1
(If the device is Android)
On the smartphone, select [Wi-Fi], and select the SSID displayed on this unit.
(If the device is iOS)
On the smartphone, select the SSID displayed on this unit from the Wi-Fi setup menu.
2 (If the device is Android)
Enter the Password displayed on this unit.
(If the device is iOS)
After entering the Password displayed on this unit, start up the
“Image App”.
3 Follow the on-screen instructions of the smartphone to set up a connection.
≥ When the settings is complete, the smartphone and this unit are connected directly, allowing you
to use remote operations. (l 154)
Connecting with Android (non-NFC-compatible) or iOS device
To Next Page
