16 Shoe adaptor mounting part
[SHOE ADAPTOR] (l 247)
17 series/ series/
series
Status indicator (l 17, 182)
Status indicator (l 17)
18 Recording start/stop button (l 25)
19 LCD monitor (Touch screen) (l 19)
≥ It can open up to 90o.
≥ It can rotate up to 180o A towards the lens or
90o B towards the opposite direction.
20 Battery holder (l 11)
21 Shoulder strap fixture
22 Tripod receptacle
≥ Attaching a tripod with a screw length of
5.5 mm or more may damage the unit.
23 SD card cover (l 16)
24 Access lamp [ACCESS] (l 16)
25 Card slot (l 16)
26 Photoshot button [ ] (l 27)
27 Zoom lever [W/T] (In Motion Picture
Recording Mode or Still Picture
Recording Mode) (l 44)/
Thumbnail display switch [ / ]/
Volume lever [sVOLr] (In Playback
Mode) (l 31)
22
23
24
25
26
27
