KW8M Eco-POWER METER
63
(Common to AKW8 series)
Data item
(MEWTOCOL)
Name Unit
Kind of
data
Range: Hexadecimal
(Range: Decimal)
MODBUS
Function
code
006BH
(DT00107)
Current
L1A(CT1)
0.1A
Unsigned
16bit
0H to EA60H (0 to 60000) 03H
006CH
(DT00108)
Current
L2A(CT2)
0.1A
Unsigned
16bit
0H to EA60H (0 to 60000) 03H
006DH
(DT00109)
Current
L3A(CT3)
0.1A
Unsigned
16bit
0H to EA60H (0 to 60000) 03H
006FH
(DT00111)
Power factor 0.01
Signed
16bit
FF9DH to 64H (-100 to 100) 03H
0070H
(DT00112)
Frequency 0.1Hz
Unsigned
16bit
0H to 3E8H (0 to 1000) 03H
0096H<LSB>
(DT00150)
Load ON-time 0.1h
Unsigned
32bit
0H to F423FH (0 to 999999)
03H/
06H/10H
0097H<MSB>
(DT00151)
0098H<LSB>
(DT00152)
Load OFF-time 0.1h
Unsigned
32bit
0H to F423FH (0 to 999999)
03H/
06H/10H
0099H<MSB>
(DT00153)
009AH<LSB>
(DT00154)
Pulse count value －
Unsigned
32bit
0H to 5F5E0FFH
(0 to 999999999)
03H/
06H/10H
009BH<MSB>
(DT00155)
009EH<LSB>
(DT00158)
Preset value －
Unsigned
32bit
0H to 5F5E0FFH
(0 to 999999999)
03H/
06H/10H
009FH<MSB>
(DT00159)
00A0H<LSB>
(DT00160)
Prescale value 0.001
Unsigned
32bit
0H to 186A0H (0 to 100000)
03H/
06H/10H
00A1H<MSB>
(DT00161)
00A2H
(DT00162)
Max.
counting speed
Hz
Unsigned
16bit
1EH (30), 7D0H (2000)
03H/
06H/10H
00A3H
(DT00163)
Auto-off time min
Unsigned
16bit
0H to 63H (0 to 99)
03H/
06H/10H
00AAH<LSB>
(DT00170)
Voltage L1V
(Between P1-P0)
0.1V
Unsigned
32bit
0H to 1869FH (0 to 99999) 03H
00ABH<MSB>
(DT00171)
00ACH<LSB>
(DT00172)
Voltage L2V
(Between P2-P0)
0.1V
Unsigned
32bit
0H to 1869FH (0 to 99999) 03H
00ADH<MSB>
(DT00173)
00AEH<LSB>
(DT00174)
Voltage L3V
(Between P3-P0)
0.1V
Unsigned
32bit
0H to 1869FH (0 to 99999) 03H
00AFH<MSB>
(DT00175)
00B0H<LSB>
(DT00176)
Instantaneous
active power
0.01kW
Unsigned
32bit
0H to 5F5E0FFH (0 to 99999999) 03H
00B1H<MSB>
(DT00177)
00B2H<LSB>
(DT00178)
Instantaneous
reactive power
0.01
kvar
Signed
32bit
FF676981H to 5F5E0FFH
(-9999999 to 99999999)
03H
00B3H<MSB>
(DT00179)
