Panasonic KW8M - Page 73

KW8M Eco-POWER METER
64
Data item
(MEWTOCOL)
Name Unit
Kind of
data
Range: Hexadecimal
(Range: Decimal)
MODBUS
Function
code
00B4H<LSB>
(DT00180)
Instantaneous
apparent power
0.01kVA
Unsigned
32bit
0H to 5F5E0FFH
(000 to 99999999)
03H
00B5H<MSB>
(DT00181)
(Only for AKW8111H)
Data item
(MEWTOCOL)
Name Unit
Kind of
data
Range: Hexadecimal
(Range: Decimal)
MODBUS
Function
code
0001H
(DT00001)
Contact output
status
－
Unsigned
16bit
0H(0)<OFF>,1H(1)<ON> 03H
0030H
(DT00048)
Hysteresis for
demand alarm off
%
Unsigned
16bit
0H to 64H (0 to 100)
03H/
06H/10H
0031H
(DT00049)
Demand monitor
start time
minute
Unsigned
16bit
1H to 1EH (1 to30)
03H/
06H/10H
4E20H
(DT20000)
Log data
(Year/Month)
－
Unsigned
16bit
Y:00H to 99H, M:01H to 12H 03H
4E21H
(DT20001)
Log data
(Date/Hour)
－
Unsigned
16bit
D:01H to 31H, H:00H to 23H 03H
4E22H
(DT20002)
Log data
(Minute + Spare)
－
Unsigned
16bit
M:00 to 59H 03H
4E23H<LSB>
(DT20003)
Log data
Integral active
Power
0.01
kWh
Unsigned
32bit
0H to 3B9AC9FFH
(0 to 999999999)
03H
4E24H<MSB>
(DT20004)
4E25H<LSB>
(DT20005)
Log data
Integral
reactive power
0.01
kvarh
Unsigned
16bit
0H to 3B9AC9FFH
(0 to 999999999)
03H
4E26H<MSB>
(DT20006)
4E27H<LSB>
(DT20007)
Log data
Integral
apparent power
0.01
kVAh
Unsigned
16bit
0H to 3B9AC9FFH
(0 to 999999999)
03H
4E28H<MSB>
(DT20008)
4E29H<LSB>
(DT20009)
Log data
Voltage L1V
0.1V
Unsigned
32bit
0H to 1869FH
(0 to 99999)
03H
4E2AH<MSB>
(DT20010)
4E2BH<LSB>
(DT20011)
Log data
Voltage L2V
0.1V
Unsigned
32bit
0H to 1869FH
(0 to 99999)
03H
4E2CH<MSB>
(DT20012)
4E2DH<LSB>
(DT20013)
Log data
Voltage L3V
0.1V
Unsigned
32bit
0H to 1869FH
(0 to 99999)
03H
4E2EH<MSB>
(DT20014)
4E2FH
(DT20015)
Log data
Current 1A(CT1)
0.1A
Unsigned
16bit
0H to EA60H
(0 to 60000)
03H
4E30H
(DT20016)
Log data
Current 2A(CT2)
0.1A
Unsigned
16bit
0H to EA60H
(0 to 60000)
03H
4E31H
(DT20017)
Log data
Current 3A(CT3)
0.1A
Unsigned
16bit
0H to EA60H
(0 to 60000)
03H
4E32H<LSB>
(DT20018)
Log data
Pulse count value
－
Unsigned
32bit
0H to 5F5E0FFH
(0 to 99999999)
03H
4E33H<MSB>
(DT20019)
