KW8M Eco-POWER METER
65
(Only for AKW8111H)
Data item
(MEWTOCOL)
Name Unit
Kind of
data
Range: Hexadecimal
(Range: Decimal)
MODBUS
Function
code
F6CCH
(DT63180)
Log data
(Year/Month)
－
Unsigned
16bit
Y:00H to 99H, M:01H to 12H 03H
F6CDH
(DT63181)
Log data
(Date/Hour)
－
Unsigned
16bit
D: 01H to 31H,H:00H to 23H 03H
F6CEH
(DT63182)
Log data
(Minute + Spare)
－
Unsigned
16bit
M: 00 to 59H 03H
F6DFH<LSB>
(DT63183)
Log data
Integral
active power
0.01kWh
Unsigned
32bit
0H to 3B9AC9FFH
(0 to 999999999)
03H
F6D0H<MSB>
(DT63184)
F6D1H<LSB>
(DT63185)
Log data
Integral
reactive power
0.01
kvarh
Unsigned
32bit
0H to 3B9AC9FFH
(0 to 999999999)
03H
F6D2H<MSB>
(DT63186)
F6D3H<LSB>
(DT63187)
Log data
Integral
apparent power
0.01
kVAh
Unsigned
32bit
0H to 3B9AC9FFH
(0 to 999999999)
03H
F6D4H<MSB>
(DT63188)
F6D5H<LSB>
(DT63199)
Log data
Voltage L1V
0.1V
Unsigned
32bit
0H to 1869FH (0 to 99999) 03H
F6D6H<MSB>
(DT63190)
F6D7H<LSB>
(DT63191)
Log data
Voltage L2V
0.1V
Unsigned
32bit
0H to 1869FH (0 to 99999) 03H
F6D8H<MSB>
(DT63192)
F6D9H<LSB>
(DT63193)
Log data
Voltage L3V
0.1V
Unsigned
32bit
0H to 1869FH (0 to 99999) 03H
F6DAH<MSB>
(DT63194)
F6DBH
(DT63198)
Log data
Current L1A(CT1)
0.1A
Unsigned
16bit
0H to EA60H (0 to 60000) 03H
F6DCH
(DT63196)
Log data
Current L2A(CT2)
0.1A
Unsigned
16bit
0H to EA60H (0 to 60000) 03H
F6DDH
(DT63197)
Log data
Current L3A(CT3)
0.1A
Unsigned
16bit
0H to EA60H (0 to 60000) 03H
F6DEH<LSB>
(DT63198)
Log data
Pulse count value
－
Unsigned
32bit
0H to 5F5E0FFH
(0 to 99999999)
03H
F6EFH<MSB>
(DT63199)
0047H
(DT00071)
Calendar timer
monitor
(Hour/Minute)
－
Unsigned
16bit
H:00H to 23H, M:00H to 59H 03H
0048H
(DT00072)
Calendar timer
(Minute/Second)
－
Unsigned
16bit
M:00H to 59H, S:00H to 59H
03H/
06H/10H
0049H
(DT00073)
Calendar timer
(Date/Hour)
－
Unsigned
16bit
D:01H to 31H, H:00H to 23H
03H/
06H/10H
004AH
(DT00074)
Calendar timer
(Year/Month)
－
Unsigned
16bit
Y:00H to 99H, M:01H to 12H
03H/
06H/10H
004BH
(DT00075)
Calendar timer
(Day)
－
Unsigned
16bit
Day:00H to 06H
03H/
06H/10H
004CH
(DT00076)
Logging cycle
setting
－
Unsigned
16bit
6 types;
1H(1)<1>,2H(2)<5>,
3H(3)<10>,4H(4)<15>,
5H(5)<30>,6H(6)<60>
03H/
06H/10H
