KX-FLB802CX/KX-FLB812CX/KX-FLB802CXS/KX-FLB812CXS
Descriptions of Pin Distribution (IC600)
PIN No. SIGNAL I/O POWER SUPPLY VOLTAGE EXPLANATION
A1 SBA[2] O 3.3V SYSTEM ADDRESS BUS 2
A2 SBA[1] O 3.3V SYSTEM ADDRESS BUS 1
A3 SBA[0] O 3.3V SYSTEM ADDRESS BUS 0
A4 SBACK O 3.3V LAN READY SIGNAL INPUT
A5 SBD[13] I/O 3.3V SYSTEM DATA BUS 13/FROM ADDRESS 18
A6 SBD[10] I/O 3.3V SYSTEM DATA BUS 10/FROM ADDRESS 15
A7 SBD[7] I/O 3.3V SYSTEM DATA BUS 7
A8 SBD[4] I/O 3.3V SYSTEM DATA BUS 4
A9 SBD[1] I/O 3.3V SYSTEM DATA BUS 1
A10 SBRD O 3.3V RD SIGNAL
A11 GPIO[47] O 3.3V NOT USED
A12 SPIDI I 3.3V(5V torelant) CIS INTERFACE
A13 SPICLK O 3.3V CIS INTERFACE
A14 GPIO[5] I 3.3V(5V torelant) INPUT PORT(USBPWR)
A15 GPIO[2] O 3.3V NOT USED
A16 GPIO[35] O 3.3V NOT USED
A17 GPIO[34] O 3.3V NOT USED
A18 TCK I 3.3V(5V torelant) JTAG INTERFACE
B1 SBA[5] O 3.3V SYSTEM ADDRESS BUS 5
B2 SBA[4] O 3.3V SYSTEM ADDRESS BUS 4
B3 SBA[3] O 3.3V SYSTEM ADDRESS BUS 3
B4 SBD[15] I/O 3.3V SYSTEM DATA BUS 15/FROM ADDRESS 20
B5 SBD[12] I/O 3.3V SYSTEM DATA BUS 12/FROM ADDRESS 17
B6 SBD[9] I/O 3.3V SYSTEM DATA BUS 9/FROM ADDRESS 14
B7 SBD[6] I/O 3.3V SYSTEM DATA BUS 6
B8 SBD[3] I/O 3.3V SYSTEM DATA BUS 3
B9 SBD[0] I/O 3.3V SYSTEM DATA BUS 0
B10 GPIO[82] O 3.3V NOT USED
B11 SBCS[2] O 3.3V MODEM CHIP SELECT OUTPUT
B12 SPIDO O 3.3V CIS INTERFACE
B13 GPIO[7] O 3.3V NOT USED
B14 GPIO[4] O 3.3V NOT USED
B15 GPIO[1] I 3.3V(5V torelant) MODEM INTERRUPT INPUT
B16 GPIO[36] O 3.3V NOT USED
B17 TDI I 3.3V(5V torelant) JTAG INTERFACE
B18 TRST I 3.3V(5V torelant) JTAG INTERFACE
C1 SBA[8] O 3.3V SYSTEM ADDRESS BUS 8
C2 SBA[7] O 3.3V SYSTEM ADDRESS BUS 7
C3 SBA[6] O 3.3V SYSTEM ADDRESS BUS 6
C4 SBD[14] I/O 3.3V SYSTEM DATA BUS 14/FROM ADDRESS 19
C5 SBD[11] I/O 3.3V SYSTEM DATA BUS 11/FROM ADDRESS 16
C6 SBD[8] I/O 3.3V SYSTEM DATA BUS 8/FROM ADDRESS 13
C7 SBD[5] I/O 3.3V SYSTEM DATA BUS 5
C8 SBD[2] I/O 3.3V SYSTEM DATA BUS 2
C9 SBWR O 3.3V WR SIGNAL
C10 SBCS[4] O 3.3V LAN CHIP SELECT OUTPUT
C11 SBCS[1] O 3.3V ASIC CHIP SELECT OUTPUT
C12 SBCS[0] O 3.3V FLASH CHIP SELECT OUTPUT
C13 GPIO[6] O 3.3V FROM ADDRESS 21
C14 GPIO[3] I 3.3V(5V torelant) LAN INTERRUPT INPUT
C15 GPIO[0] I 3.3V(5V torelant) ASIC INTERRUPT INPUT
C16 GPIO[37] O 3.3V NOT USED
C17 TDO O 3.3V JTAG INTERFACE
C18 TMS I 3.3V(5V torelant) JTAG INTERFACE
D1 SBA[11] O 3.3V SYSTEM ADDRESS BUS 11
D2 SBA[10] O 3.3V SYSTEM ADDRESS BUS 10
D3 SBA[9] O 3.3V SYSTEM ADDRESS BUS 9
D4 VDD18 - 1.8V POWER SOURCE
D5 VDD18 - 1.8V POWER SOURCE
D6 VDD33 - 3.3V POWER SOURCE
D7 VDD33 - 3.3V POWER SOURCE
D8 VDD18 - 1.8V POWER SOURCE
D9 VDD33 - 3.3V POWER SOURCE
D10 VSS33 - GND GND
D11 VDD18 - 1.8V POWER SOURCE
