Panasonic KX-FLB802CX - Page 315

315
KX-FLB802CX/KX-FLB812CX/KX-FLB802CXS/KX-FLB812CXS
19.2.5. ANALOG BOARD PARTS
R742 ERJ3GEYJ101 100
R743 ERJ3GEYJ101 100
R744 ERJ3GEYJ101 100
R745 ERJ3GEYJ473 47k
R746 ERJ3GEYJ472 4.7k
R747 ERJ6GEY0R00 0
R748 ERJ3GEYJ101 100
R749 ERJ3GEYJ753 75k
R750 ERJ3GEYJ101 100
R751 ERJ3GEYJ101 100
R752 ERJ3GEYJ101 100
R755 ERJ3GEYJ103 10k
R756 ERJ3GEYJ472 4.7k
R757 ERJ3GEYJ102 1k
R758 ERJ3GEYJ244 240k
R759 ERJ3GEYJ103 10k
R760 ERJ3GEYJ101 100
R761 ERJ3GEYJ101 100
R762 ERJ3GEYJ472 4.7k
R763 ERJ6GEY0R00 0
R764 ERJ3GEYJ103 10k
R765 ERJ3GEYJ100 10
R766 ERJ3GEYJ562 5.6k
R767 ERJ3GEYJ562 5.6k
R768 ERJ3GEYJ562 5.6k
R769 ERJ3GEYJ562 5.6k
R770 ERJ3GEYJ563 56k
R773 ERJ3GEYJ103 10k
R774 ERJ3GEYJ332 3.3k
R775 ERJ3GEYJ562 5.6k
R776 ERJ3GEYJ332 3.3k
R777 ERJ3GEYJ562 5.6k
R780 ERJ3GEYJ332 3.3k
R788 PQ4R18XJ100 10 S
R791 ERJ3GEYJ154 150k
R792 ERJ3GEYJ103 10k
R793 ERJ3GEYJ124 120k
R794 ERJ3GEYJ103 10k
R795 ERJ3GEYJ102 1k
R796 ERJ3GEYJ103 10k
R799 ERJ2GE0R00 0
R800 ERJ3GEY0R00 0
R808 ERJ2GEJ470 47
R809 ERJ2GEJ330 33
R810 ERJ2GEJ470 47
R811 ERJ2GEJ470 47
R812 ERJ2GEJ470 47
R813 ERJ2GEJ470 47
R814 ERJ3GEYJ101 100
R815 ERJ3GEYJ220 22
R817 ERJ8GEYJ2R2 2.2
R818 ERJ8GEYJ2R2 2.2
R819 ERJ8GEYJ2R2 2.2
R820 ERJ12RQJR22 0.22
R821 ERJ12RQJR22 0.22
R822 ERJ2GEJ471 470
R826 ERJ3GEYJ103 10k
R827 ERJ3GEYJ103 10k
R829 ERJ3GEYJ103 10k
R830 ERJ3GEY0R00 0
R832 ERJ2GEJ471 470
R833 ERJ2GEJ471 470
R834 ERJ2GEJ471 470
R836 ERJ2GEJ470 47
R837 ERJ2GEJ470 47
R838 ERJ2GEJ470 47
R839 ERJ2GEJ470 47
R840 ERJ2GEJ470 47
R841 ERJ2GEJ470 47
R842 ERJ2GEJ470 47
R843 ERJ2GEJ470 47
R844 ERJ2GEJ470 47
R845 ERJ2GEJ470 47
Ref.
No.
Part No. Part Name & Description Remarks
R846 ERJ2GEJ470 47
R847 ERJ2GEJ470 47
R848 ERJ2GEJ470 47
R849 ERJ2GEJ470 47
R850 ERJ2GEJ470 47
R851 ERJ2GEJ470 47
R868 ERJ3GEYJ471 470
R870 ERJ3GEYJ473 47k
R872 ERJ3GEYJ332 3.3k
R901 ERJ3GEY0R00 0
R902 ERJ8GEY0R00 0
R903 ERJ3GEYJ222 2.2k
R904 ERJ3GEYJ472 4.7k
R905 ERJ3GEYJ103 10k
R906 ERJ2GEJ470 47
R907 ERJ2GEJ470 47
R908 ERJ2GEJ470 47
R909 ERJ2GEJ470 47
R910 ERJ2GEJ470 47
R911 ERJ2GEJ470 47
R912 ERJ2GEJ470 47
R913 ERJ2GEJ470 47
R914 ERJ2GEJ470 47
R915 ERJ2GEJ470 47
R916 ERJ2GEJ470 47
(COMPONENTS PARTS)
RA600 EXB38V473JV RESISTOR ARRAY
RA601 EXB38V473JV RESISTOR ARRAY
RA602 D1H83304A010 RESISTOR ARRAY S
RA603 D1H83304A010 RESISTOR ARRAY S
RA604 D1H83304A010 RESISTOR ARRAY S
RA607 EXRV8V470JV RESISTOR ARRAY S
RA608 EXRV8V470JV RESISTOR ARRAY S
RA611 D1H83304A010 RESISTOR ARRAY S
RA612 D1H83304A010 RESISTOR ARRAY S
RA613 D1H83304A010 RESISTOR ARRAY S
RA614 D1H83304A010 RESISTOR ARRAY S
RA615 D1H83304A010 RESISTOR ARRAY S
RA616 D1H83304A010 RESISTOR ARRAY S
RA617 D1H83304A010 RESISTOR ARRAY S
RA618 D1H83304A010 RESISTOR ARRAY S
RA619 D1H83304A010 RESISTOR ARRAY S
RA620 D1H83304A010 RESISTOR ARRAY S
RA621 EXB38V473JV RESISTOR ARRAY
RA622 EXB38V473JV RESISTOR ARRAY
RA623 EXB38V473JV RESISTOR ARRAY
RA624 EXB38V473JV RESISTOR ARRAY
RA625 EXB38V473JV RESISTOR ARRAY
RA626 EXB38V473JV RESISTOR ARRAY
RA627 D1H83304A010 RESISTOR ARRAY S
RA628 D1H83304A010 RESISTOR ARRAY S
RA629 EXB38V101JV RESISTOR ARRAY
RA630 EXB38V101JV RESISTOR ARRAY
RA631 EXB38V220JV RESISTOR ARRAY
(CRYSTAL OSCILLATORS)
X600 H1A4805B0022 CRYSTAL OSCILLATOR
X601 H0A327200096 CRYSTAL OSCILLATOR
X602 H0J222500002 CRYSTAL OSCILLATOR
X603 H0J250500055 CRYSTAL OSCILLATOR
X604 H0J282500008 CRYSTAL OSCILLATOR
X605 H2A419400008 CRYSTAL OSCILLATOR
Ref.
No.
Part No. Part Name & Description Remarks
PCB2 PFLP1716CX-A ANALOG BOARD ASS'Y (RTL)
(ICs)
IC204 C0ABEB000075 IC
IC205 AN6123MS IC
IC206 C0ABEB000083 IC
IC207 C0JBAR000386 IC
IC209 AN6384SBE1V IC S
Ref.
No.
Part No. Part Name & Description Remarks
