Panasonic KX-FLB802CX - Page 316

316
KX-FLB802CX/KX-FLB812CX/KX-FLB802CXS/KX-FLB812CXS
(TRANSISTORS)
Q200 B1AAKL000006 TRANSISTOR(SI)
Q203 2SB1218ARL TRANSISTOR(SI)
Q204 PQVTDTC143E TRANSISTOR(SI) S
Q206 B1CCBR000001 TRANSISTOR(SI)
Q207 PQVTDTC143E TRANSISTOR(SI) S
Q210 PQVTDTC143E TRANSISTOR(SI) S
Q211 UN5110 TRANSISTOR(SI) S
Q212 PQVTDTC143E TRANSISTOR(SI) S
Q217 PQVTDTC143E TRANSISTOR(SI) S
Q218 PQVTDTC143E TRANSISTOR(SI) S
Q219 PQVTDTC143E TRANSISTOR(SI) S
(DIODES)
D200 MA4056 DIODE(SI) S
D201 MA4056 DIODE(SI) S
D202 1SS133 DIODE(SI) S
D203 1SS133 DIODE(SI) S
D204 1SS133 DIODE(SI) S
D206 1SS133 DIODE(SI) S
D207 1SS133 DIODE(SI) S
D209 B0EDER000009 DIODE(SI)
D210 MA4056 DIODE(SI) S
D211 MA4056 DIODE(SI) S
D212 1SS133 DIODE(SI) S
(CAPACITORS)
C219 ECJ1VC1H151J 150p
C220 ECUV1C104KBV 0.1
C222 ECUV1C104KBV 0.1
C226 ECJ1VC1H151J 150p
C228 ECUV1C104ZFV 0.1
C231 ECEA1VKA101 100 S
C234 ECUV1C273KBV 0.027
C238 ECJ1VB1H822K 0.0082
C239 ECUV1C104KBV 0.1
C240 ECUV1C104KBV 0.1
C241 ECUV1H680JCV 68p
C242 ECUV1C104ZFV 0.1
C243 ECUV1C104KBV 0.1
C244 ECUV1C273KBV 0.027
C247 ECEA0JK331 330 S
C250 ECUV1C104ZFV 0.1
C254 ECJ1VB1H682K 0.0068
C256 ECUV1C273KBV 0.027
C257 ECUV1H100JCV 10p
C258 ECUV1H100JCV 10p
C259 ECJ1VB1H392K 0.0039
C260 ECUV1C273KBV 0.027
C261 ECEA1CK470 47 S
C262 ECUV1H101JCV 100p
C263 ECUV1A105ZFV 1
C264 ECJ1VB1H392K 0.0039
C265 ECUV1A105ZFV 1
C267 ECJ1VB1H682K 0.0068
C268 ECUV1C104KBV 0.1
C270 ECUV1H391JCV 390p
C272 ECUV1H391JCV 390p
C273 ECUV1H103KBV 0.01
C275 ECUV1C104KBV 0.1
C276 ECEA1HKS010 1 S
C277 pFCA1HYK101M 100p S
C278 ECUV1H332KBV 0.0033
C281 ECUV1C104KBV 0.1
C289 ECUV1C683KBV 0.068
C292 ECUV1C104ZFV 0.1
C293 ECUV1A224KBV 0.22
C294 ECUV1H560JCV 56p
C295 ECUV1H122KBV 0.0012
C296 ECUV1H270JCV 27p
C297 ECUV1C104ZFV 0.1
C298 ECEA0JK221 220 S
C300 ECUV1C104ZFV 0.1
C301 ECUV1C104ZFV 0.1
C303 ECUV1C104KBV 0.1
Ref.
No.
Part No. Part Name & Description Remarks
C305 ECUV1H820JCV 82p
C306 ECUV1H820JCV 82p
C307 ECUV1H820JCV 82p
C308 ECJ1VC1H680J 68p
C309 ECKD2H681KB 680p S
C310 ECKD2H681KB 680p S
C313 ECJ1VC1H681J 680p
C314 ECUV1H104KBV 0.1
C315 ECUV1H103KBV 0.01
C316 ECUV1H101JCV 100p
C319 ECUV1H103KBV 0.01
C321 ECEA1CK470 47 S
C322 ECUV1H103KBV 0.01
C329 ECUV1C104ZFV 0.1
C349 ECUV1C683KBV 0.068
C350 ECUV1H153KBV 0.015
C351 ECJ1VB1H472K 0.0047
C352 ECUV1H100JCV 10p
C353 ECUV1H100JCV 10p
C248 F2A1H4R70014 4.7
C253 F2A1C1000030 10
C266 F2A1H2R20016 2.2
C269 F2A1C1000030 10
C299 F2A1C1000030 10
C311 F0C2E105A146 14 S
C317 F2A1C1000030 10
C330 F2A1C1000030 10
(CONNECTORS & JACKS)
CN200 K1MN28AA0019 CO NNE C TOR, 28P
CN220 K1KA06A00428 CONNECTOR,6P
CN250 K1KA04A00527 CONNECTOR,4P
(FUSE)
F200 K5G102A00041 FUSE
(CERAMIC FILTERS)
J379 PFVF1B252SDT CERAMIC FILTER S
L220 PFVF1B252SDT CERAMIC FILTER S
L221 PFVF1B252SDT CERAMIC FILTER S
L222 PFVF1B252SDT CERAMIC FILTER S
L223 PFVF1B252SDT CERAMIC FILTER S
L224 PFVF1B252SDT CERAMIC FILTER S
L225 PFVF1B252SDT CERAMIC FILTER S
L226 PFVF1B252SDT CERAMIC FILTER S
L227 PFVF1B252SDT CERAMIC FILTER S
L229 PFVF1B252SDT CERAMIC FILTER S
L230 PFVF1B252SDT CERAMIC FILTER S
L233 PFVF1B252SDT CERAMIC FILTER S
L235 PFVF1B252SDT CERAMIC FILTER S
L237 PFVF1B252SDT CERAMIC FILTER S
L238 PFVF1B252SDT CERAMIC FILTER S
L244 PFVF1B252SDT CERAMIC FILTER S
L251 PFVF1B252SDT CERAMIC FILTER S
L252 PFVF1B252SDT CERAMIC FILTER S
L253 PFVF1B252SDT CERAMIC FILTER S
L254 PFVF1B252SDT CERAMIC FILTER S
L255 PFVF1B252SDT CERAMIC FILTER S
L256 PFVF1B252SDT CERAMIC FILTER S
L257 PFVF1B252SDT CERAMIC FILTER S
L260 PFVF1B252SDT CERAMIC FILTER S
L261 PFVF1B252SDT CERAMIC FILTER S
L267 PFVF1B252SDT CERAMIC FILTER S
L268 PFVF1B252SDT CERAMIC FILTER S
L269 PFVF1B252SDT CERAMIC FILTER S
L270 PFVF1B252SDT CERAMIC FILTER S
L289 PFVF1B252SDT CERAMIC FILTER S
L290 PFVF1B252SDT CERAMIC FILTER S
L291 PFVF1B252SDT CERAMIC FILTER S
(COILS)
L258 PFLE003 COIL S
L262 PQLQR1E32A07 COIL S
L263 PQLQR1E32A07 COIL S
L264 PQLQR1E32A07 COIL S
L266 PQLQR1E32A07 COIL S
(PHOTO ELECTRIC TRANSDUCERS)
Ref.
No.
Part No. Part Name & Description Remarks
