Panasonic KX-FLB802CX - Page 317

317
KX-FLB802CX/KX-FLB812CX/KX-FLB802CXS/KX-FLB812CXS
19.2.6. TEL JACK BOARD PARTS
19.2.7. TONER SENSOR BOARD PARTS
PC200 0N3131SKU PHOTO COUPLER S
PC201 0N3131SKU PHOTO COUPLER S
PC203 B3PAB0000058 PHOTO COUPLER
S
PC205 B3PAA0000425 PHOTO COUPLER
(RESISTORS)
R211 ERJ3GEYJ333 33k
R216 ERJ3GEYJ114 110k
R218 ERJ3GEYJ433 43k
R223 ERJ3GEYJ114 110k
R225 PQ4R18XJ100 10 S
R229 ERJ3GEYJ473 47k
R230 ERJ3GEYJ331 330
R231 ERJ3GEYJ621 620
R235 ERJ3GEYJ223 22k
R236 ERJ3GEYJ104 100k
R237 ERJ3GEYJ473 47k
R238 ERJ3GEYJ393 39k
R239 PQ4R18XJ101 100 S
R240 ERJ3GEYJ103 10k
R241 ERJ3GEYJ102 1k
R242 ERJ3GEYJ334 330k
R244 ERJ3GEYJ102 1k
R248 ERJ3GEYJ105 1M
R249 ERDS2TJ150 15 S
R251 ERJ3GEYJ563 56k
R252 ERJ3GEYJ103 10k
R253 ERJ3GEYJ222 2.2k
R254 ERJ3GEYJ472 4.7k
R255 ERJ3GEYJ563 56k
R256 ERJ3GEYJ123 12k
R258 ERJ3GEYJ103 10k
R261 ERJ3GEYJ104 100k
R262 ERJ3GEYJ103 10k
R264 ERJ3GEYJ243 24k
R265 ERJ3GEYJ103 10k
R266 ERJ3GEYJ104 100k
R267 ERJ3GEYJ562 5.6k
R269 ERJ3GEYJ104 100k
R270 ERJ3GEYJ821 820
R271 ERJ3GEYJ223 22k
R272 ERJ3GEYJ243 24k
R273 ERDS2TJ150 15 S
R274 ERJ3GEYJ102 1k
R275 ERJ3GEYJ101 100
R276 ERJ3GEYJ392 3.9k
R282 ERJ3GEYJ153 15k
R286 ERJ3GEYJ303 30k
R287 ERJ3GEYJ683 68k
R288 ERJ3GEYJ104 100k
R289 ERJ3GEYJ473 47k
R292 ERJ3GEYJ103 10k
R293 ERJ3GEYJ102 1k
R296 ERJ3GEYJ472 4.7k
R297 ERJ3GEYJ102 1k
R298 ERJ3GEYJ104 100k
R300 ERJ3GEYJ103 10k
R301 ERJ3GEYJ562 5.6k
R302 ERJ3GEYJ222 2.2k
R303 ERJ3GEYJ183 18k
R304 ERJ3GEYJ564 560k
R305 ERJ3GEYJ333 33k
R306 ERJ3GEYJ334 330k
R307 ERJ3GEYJ183 18k
R309 PQ4R18XJ4R7 4.7 S
R315 ERJ3GEYJ124 120k
R317 ERJ3GEYJ683 68k
R318 ERJ3GEYJ474 470k
R320 ERJ3GEYJ224 220k
R321 ERJ3GEYJ224 220k
R322 ERDS1TJ473 47k S
R324 ERJ3GEYJ154 150k
R326 ERJ3GEYJ820 82
R327 ERJ3GEYJ820 82
Ref.
No.
Part No. Part Name & Description Remarks
R328 ERJ3GEYJ820 82
R329 ERJ3GEYJ102 1k
R332 ERDS1TJ682 6.8k S
R333 ERJ3GEYJ471 470
R334 ERJ3GEYJ333 33k
R335 ERJ3GEYJ822 8.2k
R338 ERJ3GEYJ222 2.2k
R340 ERJ3GEYJ681 680
R341 ERJ3GEYJ182 1.8k
R342 ERJ3GEYJ182 1.8k
R343 ERDS1TJ6R8 6.8 S
R357 ERJ3GEYJ182 1.8k
R358 ERJ3GEYJ682 6.8k
R359 ERJ3GEYJ104 100k
R360 ERJ3GEYJ104 100k
R388 ERJ3GEYJ473 47k
R389 ERJ3GEYJ473 47k
R390 ERJ3GEYJ473 47k
R391 ERJ3GEYJ473 47k
J200 ERJ3GEY0R00 0
J201 ERJ3GEY0R00 0
J202 ERJ3GEY0R00 0
J203 ERJ3GEY0R00 0
J204 ERJ3GEY0R00 0
J205 ERJ3GEY0R00 0
J213 ERJ8GEY0R00 0
L234 ERJ3GEY0R00 0
L246 ERJ3GEY0R00 0
L271 ERJ3GEY0R00 0
L272 ERJ3GEY0R00 0
L273 ERJ3GEY0R00 0
L274 ERJ3GEY0R00 0
L275 ERJ3GEY0R00 0
L276 ERJ3GEY0R00 0
R217 ERJ3GEY0R00 0
R233 ERJ3GEY0R00 0
R234 ERJ3GEY0R00 0
R245 ERJ3GEY0R00 0
R356 ERJ3GEY0R00 0
R386 ERJ8GEY0R00 0
(RELAY)
RLY200 PFSL003Z RELAY S
(TRANSFORMERS)
T201 PFLT8E003 TRANSFORMER S
T202 G4A1A0000172 TRANSFORMER
(VARISTORS)
SA200 PFRZRA311P6T VARISTOR (SURGE ABSORBER) S
SA201 J0LS00000024 VARISTOR (SURGE ABSORBER)
ZNR200 ERZVA7D151 VARISTOR
Ref.
No.
Part No. Part Name & Description Remarks
PCB3 PFLP1716CX-B TEL JACK BOARD ASS'Y (RTL)
(CONNECTOR & JACKS)
CN251 K1KA04A00527 CONNECTOR,4P
CN206 K2LB1YYB0002 JACK
CN207 K2LB1YYB0002 JACK
Ref.
No.
Part No. Part Name & Description Remarks
PCB4 PFLP1716MZ-C TONER SENSOR BOARD ASS'Y
(RTL)
(PHOTO ELECTRIC TRANSDUCER)
IC40 B4ABC0000001 PHOTO ELECTRIC TRANSDUCER
(CONNECTOR)
CN43 K1KA03A00495 CONNECTOR,3P
(CAPACITOR)
Ref.
No.
Part No. Part Name & Description Remarks
