190
KX-FT982LS-B / KX-FT984LS-B / KX-FT988LS-B
20.2.3. Digital Board Parts (KX-FT988)
R58 ERJ2GEJ124 12 0k
R59 ERJ2GEJ273X 2 7 k
R60 ERJ2GEJ473 4 7 k
R61 ERJ2GEJ335 3. 3M
R62 ERJ2GEJ272 2. 7k
R63 ERJ2GEJ333 3 3 k
R65 ERJ2GEJ220 22
R66 ERJ2GEJ224 22 0k
R67 ERJ2GEJ823 8 2 k
R68 ERJ2GEJ183 1 8 k
R69 ERJ2GEJ224 22 0k
R70 ERJ2GEJ473 4 7 k
R71 ERJ2GEJ103 1 0 k
R72 ERJ2GEJ682 6. 8k
R78 ERJ2GEJ563 5 6 k
R79 ERJ2GE0R00 0
R83 ERJ2GEJ473 4 7 k
(CAPACITORS)
C1 ECUE1C104ZFQ 0.1
C2 ECUV1H104ZFV 0.1
C3 ECUV1H104ZFV 0.1
C4 EEE1CA101WP 100 S
C5 ECUV1H104ZFV 0.1
C6 F2G1V3300012 33
C9 ECUV1A105ZFV 1
C10 ECUV1A105ZFV 1
C11 F2G0J4700032 47
C13 F2G0J4700032 47
C16 ECUE1H102KBQ 0.001
C17 ECUE1C104ZFQ 0.1
C18 ECUE1H102KBQ 0.001
C19 ECUE1H222KBQ 0.0022
C20 ECUE1H101JCQ 10 0 P
C22 ECUE1C104ZFQ 0.1
C23 ECUE1C104ZFQ 0.1
C24 ECUE1H102KBQ 0.001
C26 ECUE1H102KBQ 0.001
C27 ECUE1C104ZFQ 0.1
C28 ECUE1C104ZFQ 0.1
C30 ECUE1C104ZFQ 0.1
C31 ECUE1H120JCQ 12P
C32 ECUE1C104ZFQ 0.1
C33 ECUE1H150JCQ 15P
C34 ECUE1H102KBQ 0.001
C35 ECUE1C104ZFQ 0.1
C37 ECUE1C104ZFQ 0.1
C38 ECUE1H102KBQ 0.001
C39 ECUE1H102KBQ 0.001
C40 ECUE1H102KBQ 0.001
C41 ECUE1H102KBQ 0.001
C42 ECUE1H102KBQ 0.001
C43 ECUE1H102KBQ 0.001
C47 ECUE1H330JCQ 33P
C48 F2G0J4700032 47
C50 ECUE1H101JCQ 10 0 P
C51 ECUE1C104ZFQ 0.1
C52 ECUE1A104KBQ 0.1 S
C53 ECUE1H222KBQ 0.0022
C54 ECUV1A224KBV 0.22
C56 ECUE1E472KBQ 0.0047
C58 ECUE1H222KBQ 0.0022
C63 ECUE1C104ZFQ 0.1
C64 ECUE1H560JCQ 56P
C65 ECUV1A105ZFV 1
C67 ECUE1C104ZFQ 0.1
C68 ECUV1A105ZFV 1
C70 ECUE1C104ZFQ 0.1
C71 ECUE1C104ZFQ 0.1
C73 ECUE1H120JCQ 12P
C74 ECUE1C104ZFQ 0.1
C75 ECUE1C103KBQ 0.01
C76 ECUE1H100DCQ 10P
Safe
ty
Ref.
No.
Part No. Part Name & Description Remar
ks
C78 ECUE1A104KBQ 0.1 S
C79 ECUE1C104ZFQ 0.1
C80 ECUE1C223KBQ 0.022
C81 ECUE1H102KBQ 0.001
C82 ECUV1H104ZFV 0.1
C85 ECUE1A104KBQ 0.1
C87 ECUE1C104ZFQ 0.1
C88 F2G1C1000014 10
C89 ECUE1H820JCQ 8 2 P
C90 F2G1C1000014 10
C91 ECUE1A104KBQ 0.1
C95 ECUE1H102KBQ 0.001
C101 ECUE1A104KBQ 0.1
C102 ECUE0J105KBQ 1
C103 ECUE0J105KBQ 1
Safe
ty
Ref.
No.
Part No. Part Name & Description Remark
s
PCB1 PNWP1FT988LS DIGITAL BOARD ASS'Y (RTL)
(ICs)
IC1 C1ZBZ0003300 IC
IC2 PNWIFT988LS IC (FLASH ROM)
IC3 C0CBCBD00047 IC
IC4 C3ABKY000001 IC
IC5 C1CB00002305 IC
IC6 C3FBKC000135 IC
IC9 C0ABEB000023 IC
IC10 C0JBAS000128 IC
IC11 C0JBAA000362 IC
IC12 C1AB00002556 IC
IC15 C0CBADD00009 IC
IC16 C0JBAE000333 IC
(TRANSISTORS)
Q1 2SB1322 TRANSISTOR(SI) S
Q2 B1GBCFGG0028 TRANSISTOR(SI)
Q4 B1GBCFGG0028 TRANSISTOR(SI)
Q5 B1GBCFGG0028 TRANSISTOR(SI)
Q6 B1GBCFGG0028 TRANSISTOR(SI)
Q7 B1CHRD000003 TRANSISTOR(SI)
Q10 B1ABDF000025 TRANSISTOR(SI)
Q11 B1ABDF000025 TRANSISTOR(SI)
Q13 B1ABDF000026 TRANSISTOR(SI)
Q14 2SB1218ARL TRANSISTOR(SI)
Q15 B1GBCFJJ0048 TRANSISTOR(SI)
Q16 B1GBCFJJ0048 TRANSISTOR(SI)
IC7 B1HAGFF00015 TRANSISTOR(SI)
(DIODES)
D 1 1 1 SS 1 33 D I OD E (S I )
D12 PQVDMZJ10C DIODE(SI) S
D 1 3 P QV D MZ J 10 C D I OD E (S I) S
D 1 4 M A1 1 1 D IO D E( S I) S
(BATTERY)
BAT1 CR2032/H9B LITHIUM BATTERY
( C O N N E C T O R S )
CN1 K1KA08A00440 CONNECTOR, 8 PIN
CN2 K1KA12A00336 CONNECTOR, 12 PIN
CN3 K1KA05AA0193 CONNECTOR, 5 PIN
CN4 K1KA14A00238 CONNECTOR, 14 PIN
CN5 K1KA02A00746 CONNECTOR, 2 PIN
CN6 K1KA02A00745 CONNECTOR, 2 PIN
CN7 K1KA07A00257 CONNECTOR, 7 PIN
CN8 K1KA07A00257 CONNECTOR, 7 PIN
CN9 K1KA02A00587 CONNECTOR, 2 PIN
CN11 K1KA02A00587 CONNECTOR, 2 PIN
Safe
ty
Ref.
No.
Part No. Part Name & Description Remar
ks
