Panasonic KX-FT982LS-B - Analog Board Parts

192
KX-FT982LS-B / KX-FT984LS-B / KX-FT988LS-B
20.2.4. Analog Board Parts
C67 ECUE1C104ZFQ 0.1
C68 ECUV1A105ZFV 1
C70 ECUE1C104ZFQ 0.1
C71 ECUE1C104ZFQ 0.1
C73 ECUE1H120JCQ 12p
C74 ECUE1C104ZFQ 0.1
C75 ECUE1C103KBQ 0.01
C76 ECUE1H100DCQ 10p
C78 ECUE1A104KBQ 0.1 S
C79 ECUE1C104ZFQ 0.1
C80 ECUE1C223KBQ 0.022
C81 ECUE1H102KBQ 0.001
C82 ECUV1H104ZFV 0.1
C85 ECUE1A104KBQ 0.1
C87 ECUE1C104ZFQ 0.1
C88 F2G1C1000014 10
C89 ECUE1H820JCQ 82p
C90 F2G1C1000014 10
C91 ECUE1A104KBQ 0.1
C93 ECUE1C104ZFQ 0.1
C94 ECUE1A104KBQ 0.1
C95 ECUE1H102KBQ 0.001
C98 ECUE1A104KBQ 0.1
C99 ECUE1C103KBQ 0.01
C100 ECUE1C103KBQ 0.01
C101 ECUE1A104KBQ 0.1
C102 ECUE0J105KBQ 1
C103 ECUE0J105KBQ 1
Safe
ty
Ref.
No.
Part No. Part Name & Description Remark
s
PCB2 PNLP2002CXZ ANALOG BOARD ASS'Y (RTL)
(for KX-FT982/KX-FT984)
PCB2 PNLP2049CXZ ANALOG BOARD ASS'Y (RTL)
(for KX-FT988)
(IC)
IC101 C0ABEB000083 IC
(TRANSISTORS)
Q105 B1ABDF000026 TRANSISTOR(SI)
Q106 B1GBCFEN0010 TRANSISTOR(SI)
(DIODES)
D101 MA4120 DI O DE (S I ) S
D104 MA4030 DI O DE (S I ) S
D106 MA4030 DI O DE (S I ) S
D111 B0ADEJ000026 D I OD E (S I )
D112 B0AACK000011 D I OD E (S I )
(CONNECTOR AND JACKS)
CN101 PQJS12A10Z CONNECTOR, 12 PIN S
CN102 K2LA1YYB0001 JACK, HANDSET
CN103 K2LB1YYB0002 JACK, TEL LINE
CN104 K2LB1YYB0002 JACK, EXT. LINE
(KX-FT982/KX-FT984 only)
(SWI T C HE S)
SW101 K0L1BA000139 PUSH SWITCH
SW102 K0L1KA000007 PUSH SWITCH
SW103 PFSH1A03Z PUSH SWITCH S
( C O I L S )
L107 PQLQR2KA113 COIL S
L108 PQLQR2KA113 COIL S
L109 PQLQR2KA113 COIL S
L110 PQLQR2KA113 COIL S
L111 PQLQR2KA20T COIL S
L112 PQLQR2KA20T COIL S
L113 PQLQR2KA20T COIL
(KX-FT982/KX-FT984 only)
S
Safe
ty
Ref.
No.
Part No. Part Name & Description Remark
s
L114 PQLQR2KA20T COIL
(KX-FT982/KX-FT984 only)
S
(PHOTO ELECTRIC TRANS-
DUCER)
PC102 0N3181 PHOTO COUPLER S
(THERMISTOR)
POS101 PFRT002 THERMISTOR S
( R E L A Y )
RLY101 K6B1CYY00005 RELAY
( V A R I S T O R S )
SA101 PFRZRA311P6T VARISTOR (Surge Absorber) S
SA102 PFRZRA102P6T VARISTOR (Surge Absorber) S
( T R A N S F O R M E R )
T101 G4AYA0000016 TRANSFORMER
(RESISTORS)
L106 ERJ3GEY0R00 0
R101 ERJ3GEYJ103 1 0 k
R102 ERJ3GEYJ103 1 0 k
R103 ERJ3GEYJ220 22
R106 ERJ3GEYJ333 3 3 k
R107 ERJ3GEYJ333 3 3 k
R108 ERJ3GEYJ274 270k
R109 ERJ3GEYJ163 1 6 k
R110 ERJ3GEYJ163 1 6 k
R111 ERJ3GEYJ512 5.1k
R112 ERJ3GEYJ562 5.6k
R114 ERDS2TJ331 330 S
R117 ERJ3GEYJ822 8.2k
R118 ERJ3GEYJ433 4 3 k
R122 ERDS1TJ223 22 k S
R127 ERG2SJ121 120
R128 ERJ3GEYJ123 1 2 k
R129 ERJ3GEYJ754 750k
R130 ERJ3GEYJ754 750k
R133 ERDS1TJ153 15 k S
R134 ERJ3GEYJ473 4 7 k
R135 ERJ3GEYJ331 330
R138 ERJ3GEYJ912 9.1k
R139 ERJ3GEYJ912 9.1k
R142 ERJ3GEYJ152 1.5k
R143 ERJ3GEYJ152 1.5k
R145 ERJ3GEYJ331 330
(CAPACITORS)
C101 ECEA0JKA470 47
C102 ECEA0JKA470 47
C103 ECUV1E104ZFV 0.1
C104 ECUV1H561KBV 560p
C105 ECUV1H561KBV 560p
C106 ECUV1H101JCV 100p
C107 ECUV1H562KBV 0.0056
C108 ECUV1C104KBV 0.1
C109 ECUV1C104KBV 0.1
C110 ECUV1H472KBV 0.0047
C111 ECUV1C393KBV 0.039
C113 ECEA1HKA4R7 4.7
C115 ECUV1H103KBV 0.01
C116 ECUV1C104KBV 0.1
C119 ECUV1C333KBV 0.033
C120 ECUV1H151JCV 150p
C121 ECUV1H151JCV 150p
C124 ECUV1H472KBV 0.0047
C126 ECUV1H101JCV 100p
C128 ECEA0JKS470 47 S
C129 ECUV1C333KBV 0.033
C130 ECUV1C333KBV 0.033
C131 ECUV1H103KBV 0.01
Safe
ty
Ref.
No.
Part No. Part Name & Description Remark
s
