2.5 Connecting Extension
To SLT
To DPT
Regarding of the PIN assignment of RJ45 (PBX side), refer to the Installation Manual.
Example: KX-DT300 Series DPT Pin Assignments
TO MAIN UNIT
/ PABX
DPT and DSS Console
KX-T7000 Series SLT
H L
T R
H L
