Panasonic KX-NS500 Getting Started

4.3.2 Registering IP Telephones
After the programming of the PBX and IP telephones is finished
(refer to "4.3.1 Assigning IP Addressing
Information"), the IP telephones must be registered to the PBX. The IP Terminal Registration Mode and
IP-CS Registration Mode settings can be changed in the Site Property—Main screen of the Web
Maintenance Console (refer to "9.2.2 PBX Configuration—[1-1] Configuration—Slot—System
Property—Site—Main" in the PC Programming Manual). Refer to the following table:
IP Terminals
IP Terminal Registration Mode/IP-CS Registration Mode
Full Automatic Mode
Extension Number
Input Mode
Manual Mode
IP-PTs
ü ü ü
KX-UT Series SIP
Phones
ü ü
*1
ü
Non-KX-UT series SIP
phones (including
P-SIP)
ü
*2
ü
*2
ü
IP-CSs
*3
ü
–
ü
ü: Available
*1
KX-UT series SIP phones will be registered automatically, in the same way as Full Automatic mode.
*2
Non-KX-UT series SIP phones must always be registered to the PBX manually, even if Full Automatic mode or Extension Number
Input mode is selected.
*3
For details about registering IP
-CSs, refer to the Installation Guide for the IP-CS.
Note
• For KX-UT series SIP phones, the SIP extension password is automatically set to
"1234".
• For IP softphones, follow the same registration procedure as IP-PTs.
Full Automatic Mode
If networking settings have been completed, when IP-PTs, KX-UT series SIP phones, or IP-CSs are connected
to the same network as the PBX, they will be registered automatically. No registration procedure is required.
Extension Number Input Mode
For IP-PTs
If networking settings have been completed, when IP-PTs are connected to the same network as the PBX,
they will be registered automatically, but extension numbers for the IP-PTs will not be set. Follow the procedure
below to register an extension number to complete registration.
1. After completing networking settings, connect the IP-PT to the same network as the PBX. The screen to
enter the extension number is displayed on the IP-PT.
2. Enter an extension number.
Note
When no extension number is entered in this step, the process will time out and the IP
-PT will be
registered without an extension number.
3. Press [ENTER] on the IP-PT.
4. Press [PAUSE] or "EXIT" on the IP-PT.
Getting Started 53
4.3.2 Registering IP Telephones

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
