Panasonic KX-TD1232 User Manual

DPT Overview
24 User Manual
1.1.3 Connection
Connect as shown.
KX-T7400 Series DPTs
→ Connect to the KX-TD816/KX-TD1232 System.
→ Connect to a single line telephone jack,
Telephone Answering Machine, or FAX for
XDP* or parallel connections.
* XDP(eXtra Device Port) expands the number of telephones available in the system by allowing an
extension port to contain two telephones. For more details, please consult with your dealer.
The included
telephone
line cord
<Back View>

Panasonic KX-TD1232 Specifications

General

Type	Hybrid PBX
Max CO Lines	12
Max Extensions	32
Power Supply	AC 120V, 60Hz
Caller ID	Yes
DISA/OGM	Yes
SMDR	Yes
Operating Temperature	0°C to 40°C
