Panasonic KX-TG4221N

45
KX-TG4221N/KX-TG4222N/KX-TG4223N/KX-TG313SK/KX-TG4224N/KX-TG4225N/KX-TGA421N
11.1.2. Handset
ձ
Remove the 2 screws.
ղ
ճ
Likewise, open the other
side of the cabinet.
մ
Remove the cabinet cover
by pushing it upward.
յ
Remove the solders and tape.
Remove the 2 screws to remove
the 2 charge terminals.
ն
շ
Remove the screw to remove
the main P. C. board.
Main P.C. board
յ
Screw
շ
2 charge terminals
ն
ն
2 screws
Cabinet cover
Cabinet body
Cabinet cover
2 screws
ձ
Solders and
Tape
Insert a plastic card.
(Ex. Used SIM card etc.)
between the cabinet body
and the cabinet cover, then
pull it along the gap to open
the cabinet.
