Panasonic KX-TGE240B

117
KX-TGE240/242/243/244/245/260/262/263/264/270/272/273/274/275/TG454/TG465/TGEA20/TGA20
Q354 2SC6054JSL TRANSISTOR(SI) S
Q701 2SA1576S TRANSISTOR(SI)(for KX-
TGE240B)(for KX-
TGE242B)(for KX-
TGE243B)(for KX-
TGE244B)(for KX-
TGE245B)(for KX-
TGE270S)(for KX-
TGE272S)(for KX-
TGE273S)(for KX-
TGE274S)(for KX-
TGE275S)(for KX-
TG465SK)
S
Q702 B1GBCFYY0020 TRANSISTOR(SI)(for KX-
TGE240B)(for KX-
TGE242B)(for KX-
TGE243B)(for KX-
TGE244B)(for KX-
TGE245B)(for KX-
TGE270S)(for KX-
TGE272S)(for KX-
TGE273S)(for KX-
TGE274S)(for KX-
TGE275S)(for KX-
TG465SK)
S
Q731 2SC6054JSL TRANSISTOR(SI)(for KX-
TGE260S)(for KX-
TGE262S)(for KX-
TGE263S)(for KX-
TGE264S)(for KX-
TG454SK)(for KX-
TGE270S)(for KX-
TGE272S)(for KX-
TGE273S)(for KX-
TGE274S)(for KX-
TGE275S)(for KX-
TG465SK)
S
Q732 2SC6054JSL TRANSISTOR(SI)(for KX-
TGE260S)(for KX-
TGE262S)(for KX-
TGE263S)(for KX-
TGE264S)(for KX-
TG454SK)(for KX-
TGE270S)(for KX-
TGE272S)(for KX-
TGE273S)(for KX-
TGE274S)(for KX-
TGE275S)(for KX-
TG465SK)
S
(DIODES)
D101 B0EDER000009 DIODE(SI) S
D142 DY2J25000L TRANSISTOR(SI)
D362 B0ECKM000008 DIODE(SI)
DA802 B0DDCL000001 DIODE(SI)
(RESISTOR ARRAYS)
RA451 EXB24V222J RESISTOR ARRAY(for KX-
TGE240B)(for KX-
TGE242B)(for KX-
TGE243B)(for KX-
TGE244B)(for KX-
TGE245B)(for KX-
TGE270S)(for KX-
TGE272S)(for KX-
TGE273S)(for KX-
TGE274S)(for KX-
TGE275S)(for KX-
TG465SK)
RA452 EXB24V272J RESISTOR ARRAY(for KX-
TGE240B)(for KX-
TGE242B)(for KX-
TGE243B)(for KX-
TGE244B)(for KX-
TGE245B)(for KX-
TGE270S)(for KX-
TGE272S)(for KX-
TGE273S)(for KX-
TGE274S)(for KX-
TGE275S)(for KX-
TG465SK)
RA501 EXB24V221JX RESISTOR ARRAY
RA601 EXB28V561JX RESISTOR ARRAY
RA611 EXB28V332JX RESISTOR ARRAY
RA651 D1H810240004 RESISTOR ARRAY S
RA652 EXB24V102JX RESISTOR ARRAY
Safety Ref.
No.
Part No. Part Name & Description Remarks
RA653 D1H810240004 RESISTOR ARRAY(for KX-
TGE240B)(for KX-
TGE242B)(for KX-
TGE243B)(for KX-
TGE244B)(for KX-
TGE245B)(for KX-
TGE270S)(for KX-
TGE272S)(for KX-
TGE273S)(for KX-
TGE274S)(for KX-
TGE275S)(for KX-
TG465SK)
S
RA655 EXB28V101JX RESISTOR ARRAY(for KX-
TGE260S)(for KX-
TGE262S)(for KX-
TGE263S)(for KX-
TGE264S)(for KX-
TG454SK)(for KX-
TGE270S)(for KX-
TGE272S)(for KX-
TGE273S)(for KX-
TGE274S)(for KX-
TGE275S)(for KX-
TG465SK)
S
(VARISTOR)
SA101 J0LE00000047 VARISTOR (SURGE
ABSORBER)
(RESISTORS)
R101 ERJ3GEYJ565 5.6M S
R102 ERJ3GEYJ565 5.6M S
R103 PQ4R10XJ184 180k S
R104 PQ4R10XJ184 180k S
R109 ERJ2GEJ823 82k S
R110 ERJ2GEJ823 82k S
R111 D0GA392JA015 3.9k S
R112 D0GA124JA015 120k S
R115 ERJ3GEYJ825 8.2M S
R116 ERJ3GEYJ825 8.2M S
R117 ERJ3GEYJ154 150k S
R118 ERJ3GEYJ154 150k S
R125 D0GA271JA015 270 S
R141 ERJ3GEYJ104 100k S
R142 PQ4R18XJ272 2.7k S
R145 ERJ2GEJ222 2.2k S
R151 D0GA104JA021 100k S
R152 D0GA104JA021 100k S
R160 ERJ3GEYJ821 820 S
R162 D0GA473JA021 47k S
R163 ERJ14YJ390U 39
R164 D0GA272JA021 2.7k S
R165 ERJ3GEYJ273 27k S
R166 ERJ3GEYJ822 8.2k S
R168 ERJ2GEJ472X 4.7k S
R178 D0GA332JA015 3.3k S
R311 D0GA103JA021 10k S
R321 ERJ2RKF1400 140 S
R322 ERJ2RKF1000 100 S
R351 ERJ2GEJ333 33k S
R352 ERJ2GEJ682 6.8k S
R354 D0GA123JA021 12k S
R355 D0GA681JA021 680 S
R356 D0GA103JA021 10k S
R371 ERJ8GEYJ1R0 1 S
R372 ERJ8GEYJ1R0 1 S
R373 D0GA681JA021 680 S
R451 ERJ2GEJ391 390(for KX-TGE240B)(for
KX-TGE242B)(for KX-
TGE243B)(for KX-
TGE244B)(for KX-
TGE245B)(for KX-
TGE270S)(for KX-
TGE272S)(for KX-
TGE273S)(for KX-
TGE274S)(for KX-
TGE275S)(for KX-
TG465SK)
S
R477 D0GA1R0JA014 1 S
R478 D0GA1R0JA014 1 S
R501 ERJ2RKF5602 56k
Safety Ref.
No.
Part No. Part Name & Description Remarks
