Panasonic KX-TGE240B

61
KX-TGE240/242/243/244/245/260/262/263/264/270/272/273/274/275/TG454/TG465/TGEA20/TGA20
12.5. Things to Do after Replacing X'tal
If repairing or replacing EPROM and X'tal, it is necessary to download the required data such as Programming data or adjustment
data, etc. in memory.
The set doesn't operate if it is not executed.
12.5.1. How to download the data
12.5.1.1. Base Unit
First, operate the PC setting according to The Setting Method of JIG (P.55).
Then download the appropriate data according to the following procedures.
12.5.1.1.1. KX-TGE240/242/243/244/245
Note:
(*1) XXX_YYY: revision number, AA: Baud rate(9600/19200/57600/115200)
"XXX_YYY” vary depending on the country version. You can find them in the batch file, PNZZ- mentioned in The Setting
Method of JIG (P.55).
12.5.1.1.2. KX-TGE260/262/263/264/270/272/273/274/275/TG454/TG465
Note:
(*2) XXX_YYY: revision number, AA: Baud rate(9600/19200/57600/115200)
"XXX_YYY” vary depending on the country version. You can find them in the batch file, PNZZ- mentioned in The Setting
Method of JIG (P.55).
Items How to download/Required adjustment
BBIC(IC501) Programming data is stored in memory. 1) System Clock adjustment.
EEPROM (IC611) Adjusted parameter data is stored in memory.
(country version batch file, default batch file,
etc.)
1) Change the address “0001” of EEPROM to “AA” to download
the data.
2) Default batch file: Execute the command “default.bat”.
3)Country version batch file: Execute the command
“TGE240_US_US_RevXXX_YYY.bat”. (*1)
4) System Clock adjustment
X'tal (X501) System clock Clock adjustment data is in EEPROM, adjust the data again
after replacing it.
1) Apply 5.5V between DCP ad DCM with DC power.
2) Input Command "sendchar sfr", then you can confirm the
current value.
3) Check X'tal Frequency.(10.368MHz ± 41Hz).
4)If the frequency is not 10.368MHz ±41Hz, adjust the
frequency of CLK executing the command "sendchar sfr xx xx
(where xx is the value)" so that the reading of the frequency
counter is 10.368MHz ±5Hz.
Items How to download/Required adjustment
BBIC(IC501) Programming data is stored in memory. 1) System Clock adjustment.
EEPROM (IC611) Adjusted parameter data is stored in memory.
(country version batch file, default batch file,
etc.)
1) Change the address “0001” of EEPROM to “AA” to download
the data.
2) Default batch file: Execute the command “default.bat”.
3)Country version batch file: Execute the command
“TGE260_US_US_RevXXX_YYY.bat” (KX-TGE260) or
“TGE270_US_US_RevXXX_YYY.bat” (KX-TGE270)(*2)
4) System Clock adjustment.
X'tal (X501) System clock Clock adjustment data is in EEPROM, adjust the data again
after replacing it.
1) Apply 5.5V between DCP ad DCM with DC power.
2) Input Command "sendchar sfr", then you can confirm the
current value.
3) Check X'tal Frequency.(10.368MHz ± 41Hz).
4)If the frequency is not 10.368MHz ±41Hz, adjust the
frequency of CLK executing the command "sendchar sfr xx xx
(where xx is the value)" so that the reading of the frequency
counter is 10.368MHz ±5Hz.
