121
KX-TGE240/242/243/244/245/260/262/263/264/270/272/273/274/275/TG454/TG465/TGEA20/TGA20
16.5.3. Charger Unit
16.5.3.1. Cabinet and Electrical Parts
LED6 B3ACB0000190 LED
LED11 B3ACB0000190 LED
LED12 B3ACB0000190 LED
LED13 B3ACB0000190 LED
LED20 B3AFB0000370 LED
(IC FILTER)
L3 J0JDC0000045 IC FILTER
(COIL)
L801 G1C2N7Z00009 COIL
(RESISTOR ARRAYS)
RA1 EXB28V103 RESISTOR ARRAY
RA2 D1H83314A013 RESISTOR ARRAY S
RA3 EXB24V331J RESISTOR ARRAY
RA4 EXB24V332JX RESISTOR ARRAY
RA5 EXB28V332JX RESISTOR ARRAY
(RESISTORS)
R2 ERJ2GEJ303 30k S
R3 D0GA152JA021 1.5k S
R4 D0GA473JA021 47k S
R6 D0GA103JA021 10k S
R7 D0GA104JA021 100k S
R8 ERJ8GEYJ4R3V 4.3 S
R9 ERJ2GEJ303 30k S
R10 ERJ3GEYJ1R0 1 S
R11 D0GA681JA021 680 S
R12 ERJ2GEJ183 18k S
R13 D0GA103JA021 10k S
R20 ERJ2GEJ303 30k S
R21 D0GA103JA021 10k S
R22 D0GA332JA015 3.3k S
R23 ERJ2GEJ391 390 S
R24 ERJ2GEJ100 10 S
R25 ERJ2GEJ222 2.2k S
R26 D0GA332JA015 3.3k S
R27 ERJ2GEJ222 2.2k S
R28 ERJ2GEJ222 2.2k S
R31 ERJ2RKF1003X 100k S
R32 D0GA104JA021 100k S
R33 ERJ2RKF1003X 100k S
R34 ERJ2GE0R00 0 S
R45 D0GBR10JA113 0.1
R50 D0GA221JA021 220 S
R51 D0GA221JA021 220 S
R54 D0GA221JA021 220 S
R56 ERJ2GE0R00 0 S
R70 D0GA470JA021 47 S
R72 ERJ2GE0R00 0 S
R80 ERJ2GEJ100 10 S
(CAPACITORS)
C11 ECUE1A104KBQ 0.1
C12 ECJ1VB0G106M 10 S
C13 ECUE1A104KBQ 0.1
C14 ECUV1C393KBV 0.039
C15 ECUE1H390JCQ 39p
C16 F1J0J2260002 22
C17 ECUE1H100DCQ 10p
C18 ECUE1H100DCQ 10p
C2 F1J0J2260002 22
C20 ECJ1VB0G106M 10 S
C21 ECUE0J105KBQ 1
C22 ECUE1A104KBQ 0.1
C24 ECUE0J105KBQ 1
C25 ECUV1A225KBV 2.2
C26 ECJ1VB0G106M 10 S
C27 ECUE1H102KBQ 0.001
C29 ECUE0J105KBQ 1
C3 F1J0J2260002 22
C30 ECUE0J105KBQ 1
C31 ECJ1VB0G106M 10 S
C32 ECUE0J105KBQ 1
C33 ECUE1A104KBQ 0.1
C34 ECUE1H390JCQ 39p
C36 ECUE1A104KBQ 0.1
Safety Ref.
No.
Part No. Part Name & Description Remarks
C37 ECJ1VB0G106M 10 S
C40 ECUE1A104KBQ 0.1
C41 ECUE1A104KBQ 0.1
C43 ECUE1A104KBQ 0.1
C44 ECUE0J105KBQ 1
C45 ECUE1A104KBQ 0.1
C46 ECUE1H100DCQ 10p S
C5 ECUE1A104KBQ 0.1
C51 ECJ1VB0G106M 10 S
C52 ECUE1H100DCQ 10p
C53 ECUE1H120JCQ 12p
C56 ECUE0J105KBQ 1
C57 ECUE0J105KBQ 1
C58 ECUE0J105KBQ 1
C6 ECUE1H680JCQ 68p
C68 ECUE0J105KBQ 1
C69 ECUE1A104KBQ 0.1
C70 ECUE1H680JCQ 68p
C71 ECUE1H680JCQ 68p
C78 ECUE1H101JCQ 100p
C79 ECUE1H101JCQ 100p
C80 ECUV1C393KBV 0.039
C801 F1G1H2R0A765 2p
C802 F1G1H1R5A765 1.5p
C806 F1G1H1R0A765 1p
C807 F1G1H3R0A765 3p
C81 ECUE1H101JCQ 100p
C82 ECUE1H102KBQ 0.001
C84 ECUE1H102KBQ 0.001
C90 ECUE1A104KBQ 0.1
C91 ECUV1C105KBV 1
C92 ECUE0J105KBQ 1
C93 ECUV1C105KBV 1
C96 ECUE1H100DCQ 10p
C97 ECUE1H100DCQ 10p
(OTHERS)
E101 PNVE1002Z BATTERY TERMINAL ABS-HB
E102 PNJT1184Z CHARGE TERMINAL (L)
E103 PNJT1185Z CHARGE TERMINAL (R)
E104 L5DYBYY00043 LIQUID CRYSTAL DISPLAY
(*3)
S
E105 PNHR1921Z TRANSPARENT PLATE, LCD PMMA-HB
E106 PNHR1920Z GUIDE, LCD ABS-HB
E107 PQHG10729Z RUBBER PARTS, RECEIVER
E108 PNJE1194Z SPECIAL SWITCH
CN4 K2HD103D0001 JACK
F1 K5H252Y00002 FUSE !
MIC100 L0CBAY000053 MICROPHONE
SW1 K0H1BB000094 PUSH SWITCH
SW2 K0H1BB000094 PUSH SWITCH
X1 H0J138500003 CRYSTAL OSCILLATOR (*2) S
Safety Ref.
No.
Part No. Part Name & Description Remarks
200 PNLC1050ZB CHARGER UNIT ASS'Y
without NAME PLATE (RTL)
(for KX-TGE242B)(for KX-
TGE243B)(for KX-
TGE244B)(for KX-
TGE245B)(for KX-
TG454SK)(for KX-TGEA20B)
200 PNLC1050ZS CHARGER UNIT ASS'Y
without NAME PLATE
(RTL)(for KX-
TGE262S)(for KX-
TGE263S)(for KX-
TGE264S)(for KX-
TGE272S)(for KX-
TGE273S)(for KX-
TGE274S)(for KX-
TGE275S)(for KX-TGEA20S)
Safety Ref.
No.
Part No. Part Name & Description Remarks
