50
KX-TGE240/242/243/244/245/260/262/263/264/270/272/273/274/275/TG454/TG465/TGEA20/TGA20
11.1.1.2. KX-TGE260
ճ
Remove the screw to remove the
Jack Holder.
screws
Jack holder
Cabinet cover
Solders
Main P.C. board
ձ
Remove the 4 screws to remove
the cabinet cover.
ղ
Remove the solders.
4 screws
