Panasonic Lumix DC-G9 User Manual

4. Focus, Brightness (Exposure) and Colour tone Settings
100
Applicable modes:
1 Select the menu.
2 Display the recording screen, and move the joystick
3/4/2/1 to move the AF area.
• To specify the person or eye to be brought into focus when
using [š], align any of the AF areas currently indicating
human subjects with the desired person or eye. For any
position where a person or eye is not located, an AF area
that operates in the same way as [Ø] will be set.
• You can change the size of the AF area by rotating the front/rear dial.
• Press the joystick to switch between the default AF area
position and the position you have set.
The enlarged display will appear when [ ] ([Pinpoint]) is
set.
3 Press the shutter button halfway to set.
• Press the joystick while the recording screen is displayed
to switch between the default AF area position and the
position you have set.
Specifying the AF area position with the joystick
> [Custom] > [Operation] > [Joystick Setting] > [D.FOCUS
Movement]
MENU

Panasonic Lumix DC-G9 Specifications

General

Sensor Size	17.3 x 13.0 mm (Four Thirds)
Image Processor	Venus Engine
Connectivity	Wi-Fi, Bluetooth
Weight	658 g (body only)
Lens Mount	Micro Four Thirds
Storage Media	Dual SD card slots (UHS-II compatible)
Sensor	Live MOS
ISO Range	ISO 200-25600 (expandable to 100-25600)
Autofocus System	Depth From Defocus (DFD) technology
Viewfinder	OLED Live View Finder, 3, 680k-dot
LCD Screen	3.0" 1, 040k-dot Free-Angle Touchscreen
Video Recording	4K UHD at 60p
Image Stabilization	5-axis in-body stabilization
Burst Shooting	20 fps (electronic shutter)
Battery Life	Approx. 400 shots
Ports	HDMI, USB 3.0
Battery	DMW-BLF19 Lithium-Ion
Dimensions	136.9 x 97.3 x 91.6 mm
Weather Sealing	Yes, Splashproof / Dustproof / Freezeproof
