Preparation
- 8 -
6 Status indicator (P14, 24, 27, 29)
7 [MENU/SET] button (P17)
8 [DISPLAY/LCD MODE] button (P42, 45)
9 [FUNC] (P76)/Delete (P39) button
10 Camera ON/OFF switch (P17)
11 Zoom lever (P35)
12 Speaker (P97)
13 Microphone (P69, 82, 117)
14 Shutter button (P29, 69)
15 Mode dial (P19)
16 Strap eyelet
• We recommend attaching the strap
when using the camera to prevent it
from dropping.
17 Lens barrel
18 [AV OUT/DIGITAL] socket (P125, 129,
134)
19 [DC IN] socket (P125, 129)
• Always use a genuine Panasonic AC
adaptor (optional).
• This camera cannot charge the battery even
though the AC adaptor (optional) is
connected to it.
20 Tripod receptacle
• When you use a tripod, make sure the
tripod is stable when the camera is
attached to it.
21 Card/Battery door (P13)
22 Release lever (P13)
In these operating instructions,
operations using the cursor button are
described with illustrations below.
e.g.:When you press the 4 button
10
12
11
13 14 15
1
1
1
1
20 21
22
