<Example (a)> When using extension settings at a different location
Service-out
Extn. No. 101
Service-out
Extn. No. 101
Service-in
Extn. No. 102
Service-out
Service-in
Service-out
Extension status
of Telephone A
Service-in
Extn. No. 101
Extension status
of Telephone B
Service-out
Service-out
Service-out
Main Office
Branch Office
Extn. No. 102
Service-out
Extn. No. 102
Service-out
Service-in
Service-in
In this example, extension user A sets his/her own extension status to "Service-out" at the main office. Then,
he/she can set another extension status to "Service-in
" at the branch office to have his/her own extension
settings available at the extension.
<Example (b)> When two users share one telephone
Service-in
Extn. No. 102
User B
Service-out
Extn. No. 102
Service-out
Extn. No. 102
Service-out
Service-in
Extn. No. 101
Service-out
User A
Extn. No. 101
Service-in
Extn. No. 101
Service-out
Extension
Status
Service-in
Service-out Service-in
In this example, extension users A and B work in shifts and use the same extension in turn. User A sets the
extension status to "Service-out" when he/she finishes work. Then, user B can set the extension status
to "Service-in" and have his/her own settings available at the extension.
Document Version 2009-11 Operating Manual 141
1.3.75 Walking Extension, Enhanced
