Panasonic PT-AE7000U PT-AT5000E PT-AE700EA PT-AE7000EH

2. Replacement Parts List
Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks
46-1
TBLG3090 RUBBER LEG (REAR)
1
MECHANICAL PARTS  47
TQFX259 LAMP EXCHANGE LABEL
1
 48
TTFA0277 TOP COVER
1
 1
TXFMK01RWDZ
INTAKE FAN ASSY
1  49
TXFKF03RWDZ
FRONT COVER ASSY
1
 2
L6FCYYYH0071
IRIS FAN
1 49-1
TKKC5273
REMOTE CONTROL RECEIVER
1
3
TBLB0095 ADJUSTER LEG
250
TXFKK01REGZ
LENS CAP ASSY
1
4
TBMV249 OPERATION SHEET
1 50-1
TKKX5109 LENS CAP STRAP
1
 5
TEEC5512 EXHAUST DUCT 1
151
TBMA413 PANASONIC BADGE
1
6
TEEC5513 EXHAUST DUCT 2
152
TBMA414 3D LOGO BADGE
1
7
TEEC5515 INTAKE DUCT
153
TQFX260 MODEL NO. LABEL
1
8
TKPB60001 SHIFT COVER
153
TQFX267 MODEL NO. LABEL
1
AT5000E
9
TKZX5273
CEILING MOUNT BOSS METAL
454
TTFA0278 TOP PANEL SUB ASSY
1
10
TMKH347 FILTER BASE SPONGE C
2 54-1
TMKB210 HOOK STRING
1
11
TMKH373 DUST SPONGE 4
1 54-2
TMKY230 TOP PANEL HOOK
1
12
TMKH377 DUST SPONGE 7
1  55
TXFKP02RWDZ
LAMP COVER ASSY
1
13
TMKH378 DUST SPONGE 8
1 55-1
TMKY459 WASHER
2
14
TMKH380 VIBRATION PROOF SPONGE
1  56
TXFMZ01RWDZ
FILTER COVER ASSY
1
15
TMKZ278 WIRE PROTECTION SHEET
1  57
TXFEC01RWDZA
OPTICAL BLOCK A
1
16
TMKZ300 WIRE PROTECTION SHEET 2
1  57
TXFEC01RWDZB
OPTICAL BLOCK B
1
17
TMKZ303 DUST SHEET
1 57-1
TEEC5534 SHIFT LEVER
1
18
TUCB5061 POWER BOX COVER METAL
1 57-2
TEEC5502 LED FIX TOOL
1
 19
TXAKZ01RWDZ
EXHAUST FAN ASSY
1 57-3
TKYA47901 LENS SHIFT MASK
1
20
TMKZ283 SHADING SHEET
1 57-4
TKYA48001 LED COVER
1
 21
TTPA0572 TERMINAL COVER ASSY
1 57-5
TKYA48101 LED COVER PLATE
1
22
J0KF00000014 CLAMP CORE
1 57-6
TMKH363 MASK SHEET
1
23
TMME244 CLAMP
5 57-7
TMKZ304 SHIFTCAP
1
24
J0KG00000011
CORE
4 57-8
TMKZ301 WIRE PROTECTION SHEET 3
1
 25
L6FAYYYH0181
POWER FAN
158
TXFEC02RWDZ
ANALYSIS BLOCK
1
26
TUXK081 FAN SLEEVE
2 58-1
TENC0185 POLARIZING PLATE / IN R
1
27
TEWB856 GASKET
1 58-2
TENC0186 POLARIZING PLATE / IN B
1
28
TMKZ279 EXHAUST FAN EMC SHEET
1 58-3
TEEC5497 IRIS DUCT
1
29
TKZJ5091 POWER METAL
1 58-4
TEEC5503 LAMP DUCT L
1
30
TMKH367 DUST SPONGE 3
1 58-5
TEEC5504 LAMP DUCT R
1
 31
TMKZ280 POWER INSULATION SHEET
1 58-6
TENC5689 LAMP AIR GUIDE A
1
32
TMME279 CIRCUIT BOARD SPACER
2 58-7
TENC0172 POLARIZING PLATE / IN G
1
33
TMME363 CLAMP
1 58-8
TKGP5512 PBS ARRAY
1
34
TMXE054 PWB TOOL
2 58-9
TXZEC03RWDZ
CINEMA FILTER ASSY
1
35
TUXX696 BALLAST METAL
1 58-10
TXZEN02RWDZ
IRIS UNIT ASSY
1
36
TBXA57301 OPERATION BUTTON
1  58-11
TEKH031 GEARED MOTOR
1
 37
TXFEE01RWDZ
K4-P1 CABLE ASSY
1
with THERMAL FUSE
59
TMZX5200 FILTER CASE B
1
38
TEEC5492 LAMP HOUSE
160
TEEC5489-1 CARTRIGE CASE
1
 39
L6FCYYYH0070
LAMP FAN
161
TXFKN01RYNZP
FILTER UNIT
1
40
TEEC5494 LAMP DUCT BASE
1
41
TMKH364 DUST SPONGE 1
1
42
TMKH365 DUST SPONGE 2
1
TXJ/M3RWDZ M3-A13 CABLE
1
 43
TKFE20201 BOTTOM COVER R
1
TXJ/L2RWDZ LAMP CABLE
1
 44
TKFE20301 BOTTOM COVER L
1
TXJ/B2RWDZ B2-A4 CABLE
1
45
TKFE20401 BOTTOM COVER C
1 
TXJ/P2RWDZ-1
B1-P2 CABLE
1
 46
TTFA0276 FRAME SUB ASSY
1
TXJ/P3RWDZ-1
P3-A5 CABLE
1
SPL-6
