Panasonic PT-AE7000U PT-AT5000E PT-AE700EA PT-AE7000EH

Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks
R1952
ERJ3GEY0R00
M 0 OHM,J,1/16W
1 C2001
F1J1A106A097
CAPACITOR
1
R1953
ERJ3EKF2201
M 2.2K OHM, 1/16W
1 C2002
F1G1C104A077
C.CAPACITOR CH 16V 0.1U
1
R1954
ERJ3GEY0R00
M 0 OHM,J,1/16W
1
R1955
ERJ3EKF1002
M 10KOHM, 1/16W
1
R1956,57
ERJ3EKF51R0
M 51 OHM, 1/16W
2 R2001
ERJ3EKF5601
RESISTOR
1
R1958
ERJ3GEY0R00
M 0 OHM,J,1/16W
1 R2002
ERJ3EKF1871
RESISTOR
1
R1959
ERJ3EKF1602
M 16K OHM, 1/16W
1 R2003
ERJ3EKF3741
M 3.74K OHM,J,1/16W
1
R1960
ERJ3EKF51R0
M 51 OHM, 1/16W
1 R2004
ERJ3EKF1132
M 11.3K OHM, 1/16W
1
R1961
ERJ2GEJ101
M 100 OHM, 0.063W
1 R2005
ERJ3GEYJ102
M 1K OHM,J,1/16W
1
R1962
ERJ3EKF1002
M 10KOHM, 1/16W
1 R2006
ERJ3EKF5601
RESISTOR
1
R1963
ERJ3EKF51R0
M 51 OHM, 1/16W
1 R2007
ERJ3EKF1871
RESISTOR
1
R1964
ERJ3EKF1002
M 10KOHM, 1/16W
1 R2008
ERJ3EKF3741
M 3.74K OHM,J,1/16W
1
R1965
ERJ3EKF1001
M 1K OHM, 1/16W
1 R2009
ERJ3EKF1132
M 11.3K OHM, 1/16W
1
R1966
ERJ3EKF51R0
M 51 OHM, 1/16W
1 R2010
ERJ3EKF5601
RESISTOR
1
R1967
ERJ3GEY0R00
M 0 OHM,J,1/16W
1 R2011
ERJ3EKF1871
RESISTOR
1
R1968
ERJ2GEJ331
M 330 OHM, 0.063W
1 R2012
ERJ3EKF3741
M 3.74K OHM,J,1/16W
1
R1969
ERJ3EKF3901
M 3.9K OHM, 1/16W
1 R2013
ERJ3EKF1132
M 11.3K OHM, 1/16W
1
R1970
ERJ3EKF51R0
M 51 OHM, 1/16W
1
R1971
ERJ3EKF1002
M 10KOHM, 1/16W
1
R1972,73
ERJ3EKF51R0
M 51 OHM, 1/16W
2S1
K1KA06A00508
CONNECTOR
1
R1974
ERJ3GEY0R00
M 0 OHM,J,1/16W
1
R1975
ERJ3EKF1001
M 1K OHM, 1/16W
1
R1976,77
ERJ3GEY0R00
M 0 OHM,J,1/16W
2
SW2001-13 EVQPLHA15
SWITCH
13
R1978-80
ERJ3GEYJ104
M 100K OHM,J,1/16W
3
R1986
ERJ2GE0R00
M 0 OHM, 0.063W
1
R1988,89
ERJ2GE0R00
M 0 OHM, 0.063W
2 ZA2001
K4CD01000013
TERMINAL
1
R1990
ERJ2GEJ220
M 22 OHM, 0.063W
1
R1991,92
ERJ2GE0R00
M 0 OHM, 0.063W
2
R1993,94
ERJ2GEJ220
M 22 OHM, 0.063W
2
R1995
ERJ2GE0R00
M 0 OHM, 0.063W
1
R1996-98
ERJ2GEJ220
M 22 OHM, 0.063W
3
R1999-01
ERJ2GE0R00
M 0 OHM, 0.063W
3  V
TNPA5459 CIRCUIT BOARD V
1
(RTL)
R2004
ERJ2GEJ103
M 10K OHM, 0.063W
1
R2008-10
ERJ2GEJ220
M 22 OHM, 0.063W
3 C2101
F1G1C104A077
C.CAPACITOR CH 16V 0.1U
1
R2011
ERJ2GEJ103
M 10K OHM, 0.063W
1 C2102,03
F1J1A106A043
C.CAPACITOR CH 10V 10U
2
R2012-14
ERJ2GE0R00
M 0 OHM, 0.063W
3 C2106
F1J1A106A097
CAPACITOR
1
R2016,17
ERJ3EKF5600
M 560 OHM, 1/16W
2 C2107
F1G1C104A077
C.CAPACITOR CH 16V 0.1U
1
R2020
ERJ2GE0R00
M 0 OHM, 0.063W
1
R2021
ERJ3GEY0R00
M 0 OHM,J,1/16W
1
R2022-24
ERJ2GE0R00
M 0 OHM, 0.063W
3 D2101,02
B3AAB0000038
DIODE
2
R2025
ERJ2GEJ223
M 22K OHM, 0.063W
1 D2103
B3AGB0000051
LED
1
R2026,27
ERJ2GE0R00
M 0 OHM, 0.063W
2
R2032,33
ERJ2GEJ472
M4.7K OHM, 0.063W
2
R2034-37
ERJ2GEJ103
M 10K OHM, 0.063W
4 Q2101,02
B1GBCFJJ0007
TRANSISTOR
2
R2038
EXB28V103J
RESISTOR ARRAY
1 Q2103,04
B1GDCFJJ0008
TRANSISTOR
2
R2040,41
ERJ2GEJ220
M 22 OHM, 0.063W
2
R2045,46
ERJ2GEJ220
M 22 OHM, 0.063W
2
R2054
ERJ2GEJ223
M 22K OHM, 0.063W
1 R2101
ERJ3GEYJ470
M 47 OHM,J,1/16W
1
R2055
ERJ2GEJ472
M4.7K OHM, 0.063W
1 R2102
ERJ3GEYJ102
M 1K OHM,J,1/16W
1
R2056
ERJ2GEJ101
M 100 OHM, 0.063W
1 R2108,09
ERJ3GEYJ331
M 330 OHM,J,1/16W
2
R2058
ERJ2GEJ223
M 22K OHM, 0.063W
1 R2110
ERJ3GEYJ181
M 180 OHM,J,1/16W
1
R2111
ERJ3GEYJ182
M 1.8KOHM,J,1/16W
1
SW1000
EVQPLHA15
SWITCH
1
 SW1001
K0L1BA000104
SWITCH
1 RM2101
B3RAD0000176
REMOTE RECEIVER
1
X1000
H0J100500041
CRYSTAL
1V1
K1KA11A00178
CONNECTOR
1
X1001
H1C2705B0037
CRYSTAL
1
X1002
H0J355500001
CRYSTAL
1
X1003
H0J240500056
CRYSTAL
1 ZA2101
K4CD01000013
TERMINAL
1
X1004
H0J270500138
CRYSTAL
1
ZA1000-05
K4CD01000013
LUG TERMINAL
6
ZA1006-10
K9ZZ00001314
SHIELD CLIP
5
 L
TNPA5466 CIRCUIT BOARD L
1
(RTL)
MISCELLANEOUS  D3002-09
B3EA00000200
DIODE
8
 D3012-14
B3EA00000200
DIODE
3
215
THEC084N
SCREW (D-SUB)
4  D3016
B3EA00000200
DIODE
1
TKZF5079
TERMINAL METAL
1
TUCC6477
SHIELD METAL
1
210
XSN3+8FJK
SCREW
3L1
K1KA09A00220
CONNECTOR
1
204
XTBT969FJK
SCREW
3
211
XYN3+F6FJ
SCREW
2
ZA3001
K4CD01000013
TERMINAL
1
 S
TNPA5458 CIRCUIT BOARD S
1
(RTL)
 K1
TNPA5469 CIRCUIT BOARD K1
1
SPL-14
