Panasonic PT-RZ120

Chapter 2 Getting Started — Setting up
42 - ENGLISH
(Unit: m)
Lens type Fixed-focus Lens
Projection lens Model No. ET-DLE055 ET-DLE035
*1
Throw ratio
*2
0.785:1 0.380:1
Projected image size
Projection
distance
(L)
Height
position
(H)
*3
Projection
distance
(L1)
Distance from the
projector to the
screen
Diagonal (SD)
Height
(SH)
Width
(SW)
(L4) (A1)
1.27 (50") 0.673 1.077 0.83 0.34 ― ― ―
1.52 (60") 0.808 1.292 1.00 0.40 ― ― ―
1.78 (70") 0.942 1.508 1.18 0.47 ― ― ―
2.03 (80") 1.077 1.723 1.35 0.54 ― ― ―
2.29 (90") 1.212 1.939 1.53 0.61 ― ― ―
2.54 (100") 1.346 2.154 1.70 0.67 0.82 0.11 0.43
3.05 (120") 1.615 2.585 2.05 0.81 0.98 0.28 0.53
3.81 (150") 2.019 3.231 2.58 1.01 1.23 0.52 0.68
5.08 (200") 2.692 4.308 3.45 1.35 1.63 0.93 0.93
6.35 (250") 3.365 5.385 ― ― 2.04 1.34 1.18
7.62 (300") 4.039 6.462 ― ― 2.45 1.74 1.43
8.89 (350") 4.712 7.539 ― ― 2.85 2.15 1.69
10.16 (400") 5.385 8.616 ― ― ― ― ―
12.70 (500") 6.731 10.770 ― ― ― ― ―
15.24 (600") 8.077 12.923 ― ― ― ― ―
*1 When the Fixed-focus Lens (Model No.: ET-DLE035) is attached, the projection relation between the screen and the projector differs from that of
other lenses. Refer to “Fixed-focus Lens (Model No.: ET-DLE035)” (x page 38) for details.
*2 The throw ratio is based on the value during projection of 2.03 m (80") projected image size. When the Fixed-focus Lens (Model No.: ET-DLE035) is
attached, the throw ratio is based on the value during projection of 2.54 m (100") projected image size.
*3 When the Fixed-focus Lens (Model No.: ET-DLE055) is attached, the lens shift is not possible, therefore the height position (H) becomes the xed
value of SH/2.
r When the screen aspect ratio is 16:9
(Unit: m)
Lens type Zoom Lens
Projection lens Model No.
Standard zoom
lens/ET-DLE170
ET-DLE060 ET-DLE085 ET-DLE105 ET-DLE150
Throw ratio
*1
1.72-2.41:1 0.600-0.802:1 0.783-0.977:1 0.979-1.32:1 1.30-1.89:1
Projected image size Projection distance (L)
Diagonal (SD)
Height
(SH)
Width
(SW)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
1.27 (50") 0.623 1.107 1.87 2.64 0.64 0.87 0.85 1.07 1.06 1.45 1.42 2.07
1.52 (60") 0.747 1.328 2.26 3.19 0.78 1.05 1.03 1.29 1.29 1.75 1.71 2.49
1.78 (70") 0.872 1.550 2.65 3.73 0.92 1.24 1.21 1.51 1.51 2.05 2.00 2.92
2.03 (80") 0.996 1.771 3.04 4.27 1.06 1.42 1.39 1.73 1.73 2.35 2.30 3.34
2.29 (90") 1.121 1.992 3.43 4.82 1.20 1.60 1.57 1.95 1.96 2.64 2.59 3.77
2.54 (100") 1.245 2.214 3.82 5.36 1.34 1.79 1.75 2.17 2.18 2.94 2.89 4.19
3.05 (120") 1.494 2.657 4.60 6.45 1.62 2.16 2.10 2.62 2.63 3.54 3.47 5.04
3.81 (150") 1.868 3.321 5.76 8.08 2.04 2.71 2.64 3.28 3.29 4.44 4.36 6.31
5.08 (200") 2.491 4.428 7.71 10.80 2.74 3.63 3.54 4.39 4.41 5.93 5.82 8.43
6.35 (250") 3.113 5.535 9.65 13.51 3.44 4.55 4.43 5.50 5.52 7.43 7.29 10.55
7.62 (300") 3.736 6.641 11.60 16.23 4.14 5.47 5.33 6.61 6.64 8.93 8.76 12.67
8.89 (350") 4.358 7.748 13.55 18.95 4.84 6.39 6.23 7.72 7.76 10.42 10.23 14.79
10.16 (400") 4.981 8.855 15.49 21.66 5.54 7.31 7.12 8.83 8.87 11.92 11.70 16.91
12.70 (500") 6.226 11.069 19.38 27.10 6.93 9.15 8.91 11.05 11.10 14.91 14.64 21.15
15.24 (600") 7.472 13.283 23.27 32.53 8.33 10.99 10.71 13.27 13.33 17.90 17.58 25.39
*1 The throw ratio is based on the value during projection of 2.03 m (80") projected image size.
