Panasonic PT-RZ120

Chapter 2 Getting Started — Setting up
ENGLISH - 43
(Unit: m)
Lens type Zoom Lens Height position (H)
Projection lens Model No. ET-DLE250 ET-DLE350 ET-DLE450 Standard zoom
lens/ET-DLE170/
ET-DLE085/
ET-DLE105/
ET-DLE150/
ET-DLE250/
ET-DLE350/
ET-DLE450
ET-DLE060
Throw ratio
*1
2.27-3.62:1 3.58-5.45:1 5.36-8.58:1
Projected image size Projection distance (L)
Diagonal (SD)
Height
(SH)
Width
(SW)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
1.27 (50") 0.623 1.107 2.49 3.97 3.91 5.98 5.82 9.39
- 0.06 - 0.46 0.00 - 0.46
1.52 (60") 0.747 1.328 3.00 4.79 4.72 7.20 7.05 11.32
- 0.07 - 0.55 0.00 - 0.55
1.78 (70") 0.872 1.550 3.51 5.60 5.53 8.43 8.27 13.26
- 0.09 - 0.64 0.00 - 0.64
2.03 (80") 0.996 1.771 4.03 6.41 6.34 9.65 9.50 15.20
- 0.10 - 0.73 0.00 - 0.73
2.29 (90") 1.121 1.992 4.54 7.22 7.15 10.87 10.72 17.13
- 0.11 - 0.82 0.00 - 0.82
2.54 (100") 1.245 2.214 5.05 8.03 7.96 12.09 11.95 19.07
- 0.12 - 0.91 0.00 - 0.91
3.05 (120") 1.494 2.657 6.08 9.65 9.58 14.54 14.40 22.94
- 0.15 - 1.10 0.00 - 1.10
3.81 (150") 1.868 3.321 7.62 12.08 12.00 18.21 18.08 28.75
- 0.19 - 1.37 0.00 - 1.37
5.08 (200") 2.491 4.428 10.19 16.14 16.05 24.32 24.20 38.44
- 0.25 - 1.83 0.00 - 1.83
6.35 (250") 3.113 5.535 12.75 20.19 20.10 30.44 30.33 48.12
- 0.31 - 2.28 0.00 - 2.28
7.62 (300") 3.736 6.641 15.32 24.25 24.14 36.55 36.45 57.81
- 0.37 - 2.74 0.00 - 2.74
8.89 (350") 4.358 7.748 17.89 28.30 28.19 42.67 42.58 67.49
- 0.44 - 3.20 0.00 - 3.20
10.16 (400") 4.981 8.855 20.46 32.35 32.24 48.78 48.71 77.18
- 0.50 - 3.65 0.00 - 3.65
12.70 (500") 6.226 11.069 25.59 40.46 40.33 61.01 60.96 96.55
- 0.62 - 4.57 0.00 - 4.57
15.24 (600") 7.472 13.283 30.72 48.57 48.42 73.24 73.21 115.91
- 0.75 - 5.48 0.00 - 5.48
*1 The throw ratio is based on the value during projection of 2.03 m (80") projected image size.
(Unit: m)
Lens type Fixed-focus Lens
Projection lens Model No. ET-DLE055 ET-DLE035
*1
Throw ratio
*2
0.786:1 0.380:1
Projected image size
Projection
distance
(L)
Height
position
(H)
*3
Projection
distance
(L1)
Distance from the
projector to the
screen
Diagonal (SD)
Height
(SH)
Width
(SW)
(L4) (A1)
1.27 (50") 0.623 1.107 0.85 0.31 ― ― ―
1.52 (60") 0.747 1.328 1.03 0.37 ― ― ―
1.78 (70") 0.872 1.550 1.21 0.44 ― ― ―
2.03 (80") 0.996 1.771 1.39 0.50 ― ― ―
2.29 (90") 1.121 1.992 1.57 0.56 ― ― ―
2.54 (100") 1.245 2.214 1.75 0.62 0.84 0.14 0.51
3.05 (120") 1.494 2.657 2.11 0.75 1.01 0.30 0.63
3.81 (150") 1.868 3.321 2.65 0.93 1.26 0.56 0.81
5.08 (200") 2.491 4.428 3.55 1.25 1.68 0.97 1.10
6.35 (250") 3.113 5.535 ― ― 2.10 1.39 1.39
7.62 (300") 3.736 6.641 ― ― 2.51 1.81 1.68
8.89 (350") 4.358 7.748 ― ― 2.93 2.23 1.98
10.16 (400") 4.981 8.855 ― ― ― ― ―
12.70 (500") 6.226 11.069 ― ― ― ― ―
15.24 (600") 7.472 13.283 ― ― ― ― ―
*1 When the Fixed-focus Lens (Model No.: ET-DLE035) is attached, the projection relation between the screen and the projector differs from that of
other lenses. Refer to “Fixed-focus Lens (Model No.: ET-DLE035)” (x page 38) for details.
*2 The throw ratio is based on the value during projection of 2.03 m (80") projected image size. When the Fixed-focus Lens (Model No.: ET-DLE035) is
attached, the throw ratio is based on the value during projection of 2.54 m (100") projected image size.
*3 When the Fixed-focus Lens (Model No.: ET-DLE055) is attached, the lens shift is not possible, therefore the height position (H) becomes the xed
value of SH/2.
