Panasonic PT-RZ120

Chapter 2 Getting Started — Setting up
44 - ENGLISH
r When the screen aspect ratio is 4:3
(Unit: m)
Lens type Zoom Lens
Projection lens Model No.
Standard zoom
lens/ET-DLE170
ET-DLE060 ET-DLE085 ET-DLE105 ET-DLE150
Throw ratio
*1
2.06-2.90:1 0.724-0.965:1 0.943-1.18:1 1.18-1.59:1 1.56-2.27:1
Projected image size Projection distance (L)
Diagonal (SD)
Height
(SH)
Width
(SW)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
1.27 (50") 0.762 1.016 2.07 2.92 0.71 0.96 0.94 1.18 1.18 1.60 1.56 2.29
1.52 (60") 0.914 1.219 2.50 3.52 0.87 1.16 1.14 1.42 1.42 1.93 1.89 2.75
1.78 (70") 1.067 1.422 2.93 4.12 1.02 1.37 1.33 1.67 1.67 2.26 2.21 3.22
2.03 (80") 1.219 1.626 3.35 4.72 1.18 1.57 1.53 1.91 1.91 2.59 2.54 3.69
2.29 (90") 1.372 1.829 3.78 5.31 1.33 1.77 1.73 2.16 2.16 2.92 2.86 4.15
2.54 (100") 1.524 2.032 4.21 5.91 1.48 1.97 1.93 2.40 2.41 3.25 3.18 4.62
3.05 (120") 1.829 2.438 5.07 7.11 1.79 2.38 2.32 2.89 2.90 3.91 3.83 5.55
3.81 (150") 2.286 3.048 6.35 8.91 2.25 2.99 2.91 3.62 3.63 4.89 4.80 6.96
5.08 (200") 3.048 4.064 8.50 11.90 3.02 4.00 3.90 4.84 4.86 6.54 6.42 9.29
6.35 (250") 3.810 5.080 10.64 14.89 3.79 5.01 4.89 6.07 6.09 8.19 8.04 11.63
7.62 (300") 4.572 6.096 12.78 17.88 4.56 6.03 5.88 7.29 7.32 9.84 9.66 13.96
8.89 (350") 5.334 7.112 14.93 20.88 5.33 7.04 6.86 8.51 8.55 11.48 11.28 16.30
10.16 (400") 6.096 8.128 17.07 23.87 6.10 8.05 7.85 9.73 9.78 13.13 12.90 18.63
12.70 (500") 7.620 10.160 21.36 29.85 7.64 10.08 9.82 12.17 12.23 16.42 16.13 23.30
15.24 (600") 9.144 12.192 25.64 35.84 9.18 12.11 11.80 14.62 14.69 19.72 19.37 27.97
*1 The throw ratio is based on the value during projection of 2.03 m (80") projected image size.
(Unit: m)
Lens type Zoom Lens Height position (H)
Projection lens Model No. ET-DLE250 ET-DLE350 ET-DLE450 Standard zoom
lens/ET-DLE170/
ET-DLE085/
ET-DLE105/
ET-DLE150/
ET-DLE250/
ET-DLE350/
ET-DLE450
ET-DLE060
Throw ratio
*1
2.73-4.35:1 4.30-6.55:1 6.46-10.3:1
Projected image size Projection distance (L)
Diagonal (SD)
Height
(SH)
Width
(SW)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
1.27 (50") 0.762 1.016 2.75 4.39 4.32 6.60 6.45 10.37 0 - 0.50 0.08 - 0.50
1.52 (60") 0.914 1.219 3.31 5.28 5.21 7.95 7.80 12.50 0 - 0.60 0.09 - 0.60
1.78 (70") 1.067 1.422 3.88 6.17 6.10 9.29 9.14 14.63 0 - 0.70 0.11 - 0.70
2.03 (80") 1.219 1.626 4.44 7.07 7.00 10.64 10.49 16.77 0 - 0.80 0.12 - 0.80
2.29 (90") 1.372 1.829 5.01 7.96 7.89 11.99 11.84 18.90 0 - 0.91 0.14 - 0.91
2.54 (100") 1.524 2.032 5.57 8.85 8.78 13.34 13.19 21.03 0 - 1.01 0.15 - 1.01
3.05 (120") 1.829 2.438 6.71 10.64 10.56 16.03 15.89 25.30 0 - 1.21 0.18 - 1.21
3.81 (150") 2.286 3.048 8.40 13.32 13.24 20.07 19.94 31.70 0 - 1.51 0.23 - 1.51
5.08 (200") 3.048 4.064 11.23 17.78 17.69 26.80 26.69 42.37 0 - 2.01 0.30 - 2.01
6.35 (250") 3.810 5.080 14.06 22.25 22.15 33.54 33.44 53.04 0 - 2.51 0.38 - 2.51
7.62 (300") 4.572 6.096 16.88 26.71 26.61 40.27 40.18 63.70 0 - 3.02 0.46 - 3.02
8.89 (350") 5.334 7.112 19.71 31.18 31.06 47.01 46.93 74.37 0 - 3.52 0.53 - 3.52
10.16 (400") 6.096 8.128 22.54 35.64 35.52 53.74 53.68 85.04 0 - 4.02 0.61 - 4.02
12.70 (500") 7.620 10.160 28.19 44.58 44.43 67.21 67.17 106.37 0 - 5.03 0.76 - 5.03
15.24 (600") 9.144 12.192 33.85 53.51 53.35 80.68 80.67 127.70 0 - 6.04 0.91 - 6.04
*1 The throw ratio is based on the value during projection of 2.03 m (80") projected image size.
