Panasonic RF-800UGA - Page 41

41
VC1 RCV4RCT0V-T VARIABLE CAPACI-
TOR
1
CONNECTORS
CN1 K1KA02AA0180 2P CONNECTOR 1
CN2 K1KA06A00452 6P CONNECTOR 1
CN101 K1KA06A00452 6P CONNECTOR 1
CN104 K1KA02AA0193 2P CONNECTOR 1
CN105 K1KA02AA0193 2P CONNECTOR 1
COILS AND INDUC-
TORS
L1 RLQY10S4-0 CHOKE COIL 1
L2 RLQY30S1W RF CHOKE COIL 1
L3 RLVN5D036-C BAR ANTENNA 1
L4 RLQY30S4W COIL 1
L5 RLQY15G5-M CHOKE COIL 1
L7 RLAN3B44-C SW2 ANT COIL 1
L11 RL04P004-C FM OSC COIL 1 GS
L11 RLD4Y53W FM OSC COIL 1 GA
L12 RL0N2B108-C MW OSC COIL 1
L13 RL0N3B91-C SW1 OSC COIL 1
L14 RL0N3B95-C SW2 OSC COIL 1
L31 G0C100KA0029 INDUCTOR 1
L102 RLQB220K-C CHOKE COIL 1
TRIMMERS
CT1 F7BAF7R00002 TRIMMER 1
CT2 F7BAF7R00002 TRIMMER 1
CT11 F7BAF1100005 TRIMMER 1
CT12 F7BAF1100005 TRIMMER 1
FM IFT COIL
T1 RLI4B153-C FM IFT COIL 1
CERAMIC FILTER
CF21 J0B1075AA016 CERAMIC FILTER 1
CF22 RLFNLTZ455JL CERAMIC FILTER 1
CF23 J0B1075AA016 CERAMIC FILTER 1
CF24 J0B1075AA016 CERAMIC FILTER 1
OSCILLATOR
X101 H0H169500013 OSCILLATOR 1
FUSE PROTECTORS
FP1 K5G502A00039 FUSE PROTECTOR 1
IP1 D4FB1R100026 FUSE PROTECTOR 1
JACKS
JK1 RJJ37TK09 JK HEADPHONE 1
JK2 RJJ43K12 JK DC INLET 1
JK101 K2HC103A0031 JK MUSIC PORT 1
USB101 K1FY104A0007 USB CONNECTOR 1
CHIP JUMPERS
K101 ERJ3GEY0R00V 0 1/10W 1
IP101 D0GDR00JA055 0 1/8W 1
L33 ERJ3GEY0R00V 0 1/10W 1
L34 ERJ3GEY0R00V 0 1/10W 1
L103 ERJ3GEY0R00V 0 1/10W 1
L104 ERJ3GEY0R00V 0 1/10W 1
L105 ERJ3GEY0R00V 0 1/10W 1
L106 ERJ3GEY0R00V 0 1/10W 1
L107 ERJ3GEY0R00V 0 1/10W 1
Safety Ref. No. Part No. Part Name &
Description
Qty Remarks
L108 ERJ3GEY0R00V 0 1/10W 1
W1 ERJ3GEY0R00V 0 1/10W 1
W2 ERJ3GEY0R00V 0 1/10W 1
W201 ERJ3GEY0R00V 0 1/10W 1
W202 D0GDR00JA055 0 1/8W 1
W203 ERJ3GEY0R00V 0 1/10W 1
W204 ERJ3GEY0R00V 0 1/10W 1
W205 D0GDR00JA055 0 1/8W 1
W206 ERJ3GEY0R00V 0 1/10W 1
W207 ERJ3GEY0R00V 0 1/10W 1
W208 D0GDR00JA055 0 1/8W 1
W209 D0GDR00JA055 0 1/8W 1
W210 ERJ3GEY0R00V 0 1/10W 1
W211 D0GDR00JA055 0 1/8W 1
W212 ERJ3GEY0R00V 0 1/10W 1
W213 ERJ3GEY0R00V 0 1/10W 1
RESISTORS
R1 ERJ3GEYJ104V 100K 1/10W 1
R2 ERJ3GEYJ330V 33 1/10W 1
R3 ERJ3GEYJ330V 33 1/10W 1
R4 ERJ3GEYJ560V 56 1/10W 1
R5 ERJ3GEYJ470V 47 1/10W 1
R7 ERJ3GEYJ100V 10 1/10W 1
R8 ERJ3GEYJ820V 82 1/10W 1
R9 ERJ3GEYJ334V 330K 1/10W 1
R10 ERJ3GEYJ183V 18K 1/10W 1
R11 ERJ3GEYJ682V 6.8K 1/10W 1
R12 ERJ3GEYJ151V 150 1/10W 1
R13 ERJ3GEYJ682V 6.8K 1/10W 1
R14 ERJ3GEY0R00V 0 1/10W 1
R17 ERJ3GEYJ273V 27K 1/10W 1
R19 ERJ3GEYJ682V 6.8K 1/10W 1
R20 ERJ3GEYJ182V 1.8K 1/10W 1
R23 ERJ3GEYJ102V 1K 1/10W 1
R24 ERJ3GEYJ104V 100K 1/10W 1
R25 ERJ3GEYJ332V 3.3K 1/10W 1
R27 ERJ3GEYJ102V 1K 1/10W 1
R28 ERJ3GEYJ101V 100 1/10W 1
R29 ERJ3GEYJ471V 470 1/10W 1
R62 ERJ3GEYJ101V 100 1/10W 1
R64 ERJ3GEYJ470V 47 1/10W 1
R65 ERJ3GEYJ680V 68 1/10W 1
R66 ERJ3GEYJ103V 10K 1/10W 1
R69 ERJ3GEYJ2R2V 2.2 1/10W 1
R70 ERJ3GEYJ2R2V 2.2 1/10W 1
R74 ERJ3GEYJ101V 100 1/10W 1
R77 ERJ3GEYJ333V 33K 1/10W 1
R82 ERJ3GEYJ473V 47K 1/10W 1
R101 ERJ3GEYJ104V 100K 1/10W 1
R102 ERJ3GEYJ104V 100K 1/10W 1
R103 ERJ3GEYJ104V 100K 1/10W 1
R104 ERJ3GEYJ104V 100K 1/10W 1
R105 ERJ3GEYJ104V 100K 1/10W 1
R106 ERJ3GEYJ133V 13K 1/10W 1
R107 ERJ3GEYJ683V 68K 1/10W 1
R108 ERJ3GEYJ123V 12K 1/10W 1
R109 ERJ3GEYJ105V 1M 1/10W 1
R110 ERJ3GEYJ101V 100 1/10W 1
R111 ERJ3GEYJ222V 2.2K 1/10W 1
R112 ERJ3GEYJ222V 2.2K 1/10W 1
R113 ERJ3GEYJ221V 220 1/10W 1
R114 ERJ3GEYJ221V 220 1/10W 1
R115 ERJ3GEYJ101V 100 1/10W 1
R116 ERJ3GEYJ221V 220 1/10W 1
R117 ERJ3GEYJ103V 10K 1/10W 1
R118 ERJ3GEYJ102V 1K 1/10W 1
R119 ERJ3GEYJ102V 1K 1/10W 1
R120 ERJ3GEYJ183V 18K 1/10W 1
R121 ERJ3GEYJ183V 18K 1/10W 1
R124 ERJ3GEYJ331V 330 1/10W 1
R125 ERJ3GEYJ271V 270 1/10W 1
Safety Ref. No. Part No. Part Name &
Description
Qty Remarks
