Panasonic TH-42PV60H

6.18. Remove the front bracket
1. Unlock the cable clampers to free the cable.
2. Disconnect the couplers (G1 and G51).
3. Remove the screws (×5
) and remove the front bracket.
6.19. Remove the G-Board and GK-
Board
1. Remove the front bracket. (See section 6.21.)
2. Remove the screws (×3
) and remove the metal cover.
3. Remove the screws (×3 ) and remove the front side
metal frame.
4. Remove the screws (×3 ) and disconnect the couplers
(G3-GK3).
5. Remove the G-Board and GK-Board.
6.20. Remove the speaker L, R
1. Remove the sponge
2. Disconnect the relay couplers
3. Remove the screws (×4
) and remove the speaker L, R.
14
TH-42PV60A / TH-42PV60H / TH-42PV60M / TH-42PV60MT
