Specifications
Tuning System Frequency synthesized 100 Position ( 0 to 99 ).
RF Channels VHF 0 to 12 PAL B
UHF 21 to 69 PAL G
S’1 to S’3 HYPER TUNER
S1 to S41
Receiving Systems 1. PAL B/G Reception of Off air broadcasts
Playback from Video Tape Recorders
2. NTSC 4.43 Playback from Special Video Tape
3. NTSC 3.58 Recorders and Special Video Disc Players
4. PAL 60Hz (Via the AV Sockets) only.
Power Requirements 220 ~ 240Volts + 10% 50Hz
Power Consumption 211W Max 3W Stand-By
Chassis EURO7
Picture Tube 76cm Viewable (Measured diagonally)
Audio Output Two Way Four Speakers Plus AFB Woofer (10W + 10W + 12W)
External Speaker 10W x 4Speakers (Not supplied) TX-76PW10A
Connections
Headphone Socket 3.5mm Stereo (Main and Sub) TX-76PW10A
3.5mm Stereo (Main) TX-76PW05Z
Aerial Impedance 75Ω Unbalanced coaxial
Component Video 1080i and 576P TX-76PW10A
576P TX-76PW05A
Video / Audio Terminals AV1 IN (Rear) : S-Video, Video, Audio L/R Terminals
AV2 IN (Rear) : Video or Y/P
B
/P
R
, Audio L/R Terminals
AV3 IN (Front) : S-Video, Video, Audio L/R Terminals
AV4 IN (Rear) : Video or Y/P
B
/P
R
, Audio L/R Terminals
Digital Audio input coaxial, optical TX-76PW10A
Video / Audio Input S-Video Y : 1.0Vp-p 75Ω C: 0.3Vp-p 75Ω
Video in 1.0Vp-p, 75Ω
Audio in Approx. 400mV 1kΩ
Monitor Out Video Out 1.0Vp-p, 75Ω Audio Out Approx. 400mV 1kΩ
Accessories Supplied Remote Control EUR511226 TX-76PW10A
EUR511216 TX-76PW05A
2 Type ‘AA’ Batteries Instruction Manual TQB4A0145
Dimensions W = 77.7cm D = 53.53cm H = 61.13cm
Weight 60kg (Net)
Note:
Design and Specifications are subject to change without notice. Weight and Dimensions shown are approximate.
