After installing or moving the electronic
board, lock the casters and set the fall-
prevention extension legs.
Locking the casters
(Push this side)
Push to lock
If the unit is hung on a wall, confirm the
wall must be capable of supporting at least
the following weight.
1,005 N [103kgf (227 lbs)]
Do not attach the electronic board to mor-
tared walls. Accidental electric leakage
from the wall mounting plate bolts to metal
laths or wire laths can cause heat, smoke
or a fire.
Confirm the bolts of the unit are certainly
caught by the wall mounting plate by pull-
ing the unit after hanging the unit on the
wall mounting plate if the unit is mounted
on a wall.
Be sure to put on a glove to avoid electric
shock or injury.
30 Operating Instructions (For Basic Operations)
