Appendix
Power
source
Power supply unit (VL-PS240)
24 V DC, 0.2 A
Power
consumption
Standby: Approx. 1.9 W
During Operation: Approx. 4.5 W
Dimensions
(H x W x D)
(Excluding protruding sections)
373 x 179 x 2.5 mm (excluding sections embedded into the wall)
Weight
2.0 kg
Operating
environment
Ambient temperature: Approx. -10 °C to +55 °C,
Ambient temperature for power supply unit: 0 °C to +50°C
Relative humidity(non-condensing) :up to 90 %
(outdoor installation available; power supply unit is for indoor use only)
Display
4.3-inch monochrome display ( white backlit LCD )
Display
languages
English
Talking
method
Hands-free
Viewing
angle
Horizontally: Approx. 170°/ Vertically: Approx. 115°
Installation
method
Flush mount (flush mount
ing
box supplied)
sensor
1.0 M pixel CMOS
Minimum
illuminance
1 lx (within approx. 50cm from the camera lens)
Lighting
method
White coloured LED lights
IP
rating/IK rating
IP55*1 / Compliant with IK07*1
External
material
Stainless steel (partially ABS and PC)
Expanded
interface
Support for electric lock releasing (entrance unlocking) x 1
VIDEO-IN (recommended Panasonic Security camera) x1
Supported
functions
-
Guidance (simple usage for visitors)
-
Night colour vision ( white coloured LED lights)
-
Heat sensor
:
The backlight of the display and buttons are turned on when a visitor is detected
-
Display the resident’s names
-
Unlock with PIN-code.
10-1. Lobby Station : VL-V900 (Specifications)
