GENERAL SPECIFICATIONS
43
Print Method: Thermal transfer or direct thermal
Effective Print Width: 1.89” (48 mm)
Print Length: 20.0” (maximum label length)
Print Resolution: 203 dpi (horizontally and vertically)
Print Speed: Up to 1 ips
Feed Speed: Up to 2 ips
Label Width: 0.24” to 2.0”
Media Length: 3” diameter label roll (internal)
Media Types: Die cut or continuous tapes
Materials: Vinyl self-laminating, flattened heat shrink,
vinyl cloth, polyester, continuous tape, vinyl,
non-adhesive polyester, paper.
Media Cutting: Manually operated cutter
Ribbons: Replaceable cartridges, wax or resin
Keypad: 49 color coded keys with overlay
Display: 128 x 64 dots graphic LCD
LCD Contrast Control: Adjustable via keypad
Operating System: Panduit proprietary – user upgradeable.
User Memory: 128 Kbytes of RAM available for label storage.
Memory Card: Future - PCMCIA Type I and Type II memory cards.
Serial Port: RS-232 Serial Interface for PC hook-up or
bar code scanner.
Battery Pack: 12 VDC, 1200 mAh rechargeable NiMH
(Nickel-Metal Hydride) battery pack.
(Battery life – approx. 1500 TWS-2V labels)
AC Adapter: Universal Input (100 - 240 VAC, 50/60 Hz) with
IEC-320-C14 input connector
(accepts international cord sets).
Regulated DC Output 12 VDC, 0 to 1.2 Amp.
Powers the printer’s internal battery charger.
Charging time 15 hours.
Sound Effects: Audio speaker included
Oper. Temp/Hum: 41-104° F (5-40 °C),
0 - 90% relative humidity (non-condensing)
Stor. Temp/Hum: -40-140° F (-40-60 °C),
0 - 90% relative humidity (non-condensing)
Compliance: FCC Part 15 Class A, European Community EMC
and Low Voltage Directives regarding safety,
emissions, and immunity.
Size Height: 6.2” (157.5 mm)
Width: 4.9” (124.5mm)
Length: 13.8” (350.5 mm)
Weight 4.1 lbs. (1.86 kg) - includes battery pack
