Pantum P2200 Series Maintenance Manual

1–1
1 An Introduction to the Product
1 An Introduction to the Product ....................................................................................... 1–1
1.1 Overview ..................................................................................................................... 1–2
1.1.1 Front View ...................................................................................................... 1–2
1.1.2 Rear View ........................................................................................................ 1–3
1.1.3 Overview of the Control Panel ................................................................ 1–4
1.1.3.1 WIFI Searching Button Functions .................................................. 1–5
1.1.3.2 Cancel/Continue Button Functions ............................................... 1–6
1.1.4 Indicators ........................................................................................................ 1–7
1.1.4.1 LED1 Indicator Status Display ......................................................... 1–7
1.1.4.2 LED2 Indicator Status Display ......................................................... 1–8
1.1.4.3 Indicator Status Display ....................................................................... 1–9
1.2 Product Specifications ......................................................................................... 1–10
1.2.1 General Specifications ............................................................................ 1–10
1.2.2 Printing Specifications ............................................................................ 1–11
1.2.3 Consumables Specifications ................................................................. 1–12

Pantum P2200 Series Specifications

General

Print Technology	Monochrome Laser
Max Print Resolution	1200 x 1200 dpi
Paper Input Capacity	150 sheets
Paper Output Capacity	100 sheets
Printer Language	GDI
Processor Speed	600 MHz
Memory	64 MB
Connectivity	USB 2.0
Media Weight	60-163 g/m²
Compatible Operating Systems	Windows, Linux, Mac OS
Dimensions	337 x 220 x 178 mm
Weight	4.75 kg
First Print Out Time	Less than 7.8 seconds
Recommended Monthly Page Volume	250 to 2, 000 pages
Media Types	Plain, Cardstock, Label, Envelope, Thin
Media Sizes	A4, A5, A6, B5, Legal, Letter, Executive, DL envelope, C5 envelope, Postcard
Power Consumption	Average: 370W
Print Speed	Up to 20 ppm
