Pantum P2200 Series Maintenance Manual

2–27
2.5.2 Install the Printer to the Network
With this setting, the printer is connected directly to the network and can be set to
allow all computers on the network to print directly to this printer.
1. Before you turn on the printer, plug the network cable to the printer's network
port to connect the printer directly to the network.
2. Turn on the printer and wait for the status indicator on the control panel to
appear as ready, as shown below.
3. Insert the printer's CD into the computer. If the software installer does not start,
please find the "setup.exe" file on the CD ("setup64.exe" for 64-bit systems),
and double-click to run the file.
4. Follow the installer instructions.
5. Proceed to complete the installation.
Note:
 When the installer prompts you to select a printer, you can select the
appropriate printer name from the Detected Printer;
 If the printer name does not appear in the Detected Printer, please click Refresh
and search for printers on the network;
 If you know the IP address of the printer to be connected, you can select
Specify an IP Address for Installation to enter the IP address for installation.

Pantum P2200 Series Specifications

General

Print Technology	Monochrome Laser
Max Print Resolution	1200 x 1200 dpi
Paper Input Capacity	150 sheets
Paper Output Capacity	100 sheets
Printer Language	GDI
Processor Speed	600 MHz
Memory	64 MB
Connectivity	USB 2.0
Media Weight	60-163 g/m²
Compatible Operating Systems	Windows, Linux, Mac OS
Dimensions	337 x 220 x 178 mm
Weight	4.75 kg
First Print Out Time	Less than 7.8 seconds
Recommended Monthly Page Volume	250 to 2, 000 pages
Media Types	Plain, Cardstock, Label, Envelope, Thin
Media Sizes	A4, A5, A6, B5, Legal, Letter, Executive, DL envelope, C5 envelope, Postcard
Power Consumption	Average: 370W
Print Speed	Up to 20 ppm
