Pantum P2200 Series Maintenance Manual

6–2
6.1 Pre-maintenance Check
一、Environment
1. The power voltage must be in the range of 220~240 VAC, depending on the
model.
2. Place the equipment on a flat, stable surface.
3. Room temperature is maintained between 10°C and 32.5°C. Relative humidity
should be between 20% and 80%.
4. Do not expose the equipment to dust.
5. Do not expose the equipment to ammonia or other noxious gases.
6. Avoid exposing the equipment to heat or moisture (e.g. near water or a
humidifier).
7. Avoid exposing the equipment to direct sunlight.
8. Use the printer in a well-ventilated room.
9. Make sure the printer's air vent is not blocked.
二、About paper
1. Check whether the paper used is within the specified range. [Printing with
paper that is too thick, too thin, or curled may result in paper jams, feed
problems or poor print quality]
2. Do not use damp or wet paper. [If paper is damp or wet, please replace with dry
paper and check to see if the quality improves]
3. Do not use short-grained paper or acid paper. [If you use short-grained paper
or acid paper, it can cause print quality problems]
三、Consumables
1. Replace the cartridge when the indicator on the printer control panel flashes
yellow.
2. Check that the specified Pantum cartridge is being used. For more information,
please see 5.2"Consumables" .

Pantum P2200 Series Specifications

General

Print Technology	Monochrome Laser
Max Print Resolution	1200 x 1200 dpi
Paper Input Capacity	150 sheets
Paper Output Capacity	100 sheets
Printer Language	GDI
Processor Speed	600 MHz
Memory	64 MB
Connectivity	USB 2.0
Media Weight	60-163 g/m²
Compatible Operating Systems	Windows, Linux, Mac OS
Dimensions	337 x 220 x 178 mm
Weight	4.75 kg
First Print Out Time	Less than 7.8 seconds
Recommended Monthly Page Volume	250 to 2, 000 pages
Media Types	Plain, Cardstock, Label, Envelope, Thin
Media Sizes	A4, A5, A6, B5, Legal, Letter, Executive, DL envelope, C5 envelope, Postcard
Power Consumption	Average: 370W
Print Speed	Up to 20 ppm
