Pantum P2200 Series Maintenance Manual

6–9
6.5 Troubleshooting
6.5.1 Feed Paper Failure
Initial Check: Please conduct an initial check when there is a paper feed failure.
Check
Solution
Do the print media meet product
specifications?
Replace the print media.
Is the paper curled, wrinkled, or wet?
Replace the paper and tell users how to
protect the paper.
Is the paper path deformed, dirty, or blocked
up?
Clean the paper path and replace relevant
accessories, if needed.
Is the separation claw dirty, deformed, or
damaged?
Replace the fuser component.
Are the pickup roller and separation
component dirty, deformed or, damaged?
Clean the pickup roller and separation
component, and replace them, if needed.
Is the tray detent correctly placed to feed
paper?
Slide the tray detent closer to the edge of
the paper stack.
Is the clutch gear rotating properly?
Adjust or replace the clutch gear.
Is the electromagnet working properly?
Replace the electromagnet.

Pantum P2200 Series Specifications

General

Print Technology	Monochrome Laser
Max Print Resolution	1200 x 1200 dpi
Paper Input Capacity	150 sheets
Paper Output Capacity	100 sheets
Printer Language	GDI
Processor Speed	600 MHz
Memory	64 MB
Connectivity	USB 2.0
Media Weight	60-163 g/m²
Compatible Operating Systems	Windows, Linux, Mac OS
Dimensions	337 x 220 x 178 mm
Weight	4.75 kg
First Print Out Time	Less than 7.8 seconds
Recommended Monthly Page Volume	250 to 2, 000 pages
Media Types	Plain, Cardstock, Label, Envelope, Thin
Media Sizes	A4, A5, A6, B5, Legal, Letter, Executive, DL envelope, C5 envelope, Postcard
Power Consumption	Average: 370W
Print Speed	Up to 20 ppm
