Pantum P2200 Series Maintenance Manual

6–4
6.3 Error Code
Code
Cause
Solution
NO.000
The main motor is faulty
1. Make sure that the main motor cable is
connected correctly if the cable
connection is faulty.
2. Replace the main motor if it is faulty;
3. Replace the high voltage power board
if it is faulty.
NO.001
The LSU line
synchronizing signal is
abnormal
1. Replace the laser if there is a fault in
the LSU laser motor;
2. Replace the high voltage power board
if there is a fault in its LSU laser motor
control gear.
3. Make sure that the motor cable is
connected correctly if the motor cable
connection is faulty.
4. Replace the high voltage power board
if it is faulty
NO.002
A fault is detected in the
LSU motor
N0.003-012
1. Check the fuser component cable, and
make sure the cable is properly
connected.
2. Replace the fuser component if it is
faulty;
3. Replace the high voltage power board
if it is faulty;

Pantum P2200 Series Specifications

General

Print Technology	Monochrome Laser
Max Print Resolution	1200 x 1200 dpi
Paper Input Capacity	150 sheets
Paper Output Capacity	100 sheets
Printer Language	GDI
Processor Speed	600 MHz
Memory	64 MB
Connectivity	USB 2.0
Media Weight	60-163 g/m²
Compatible Operating Systems	Windows, Linux, Mac OS
Dimensions	337 x 220 x 178 mm
Weight	4.75 kg
First Print Out Time	Less than 7.8 seconds
Recommended Monthly Page Volume	250 to 2, 000 pages
Media Types	Plain, Cardstock, Label, Envelope, Thin
Media Sizes	A4, A5, A6, B5, Legal, Letter, Executive, DL envelope, C5 envelope, Postcard
Power Consumption	Average: 370W
Print Speed	Up to 20 ppm
