Pantum P2200 Series Maintenance Manual

6–10
M1 Paper feed failure
Possible cause
Solution
There is no electromagnet signal.
Check the electromagnet signal input to ensure that
the electromagnet signal line is normal.
The pickup roller is dirty.
Clean or replace the pickup roller.
Pickup roller wears down.
Replace the pickup roller.
M2 Continuous paper feed
Possible cause
Solution
Electromagnet signal error.
Check the electromagnet signal input to ensure that
the electromagnet signal line is normal.
The electromagnet spring hook
is not powerful enough.
Replace the electromagnet.
Incorrect assembly phase of the
clutch single set assembly.
Check the clutch single set to ensure that the
assembly phase is right.
M3 Tilt Feeding
Possible cause
Solution
The feeder channel is dirty.
Check the feeder channel to ensure that the channel
is clear.
The pickup roller is dirty.
Clean the pickup roller.
M4 Resend
Possible cause
Solution
Paper is placed incorrectly.
Confirm that the paper is placed correctly.
The separator is contaminated or
worn.
Clean or replace the separator.

Pantum P2200 Series Specifications

General

Print Technology	Monochrome Laser
Max Print Resolution	1200 x 1200 dpi
Paper Input Capacity	150 sheets
Paper Output Capacity	100 sheets
Printer Language	GDI
Processor Speed	600 MHz
Memory	64 MB
Connectivity	USB 2.0
Media Weight	60-163 g/m²
Compatible Operating Systems	Windows, Linux, Mac OS
Dimensions	337 x 220 x 178 mm
Weight	4.75 kg
First Print Out Time	Less than 7.8 seconds
Recommended Monthly Page Volume	250 to 2, 000 pages
Media Types	Plain, Cardstock, Label, Envelope, Thin
Media Sizes	A4, A5, A6, B5, Legal, Letter, Executive, DL envelope, C5 envelope, Postcard
Power Consumption	Average: 370W
Print Speed	Up to 20 ppm
