Page 20 User Codes and Labels
buttons on your keypad, press the button until the
desired letter appears on the screen. For example, if you
want to enter the letter “C” you would press the [1]
button three times (see Table 3 on page 20).
NOTE: For Hebrew, Russian and Greek keypads, refer to the
standard and special characters appendices on page 43 and
page 44.
Table 3: Keypad Letter Assignments
Special Function Keys
[STAY] = Insert Space
Pressing the [
STAY] key inserts a blank space in the current
cursor position.
[
SLEEP] = Delete
Pressing the [
SLEEP] key will delete the character or blank
space at the current cursor position.
[
ARM] = Delete Until the End
Pressing the [
ARM] key will delete all characters and
spaces to the right of the cursor and at the cursor's
position.
[
OFF] = Number Keys / Letter Keys
Key Press Key
Once
Press Key
Twice
Press Key
Three Times
[1] A B C
[2] D E F
[3] G H I
[4] J K L
[5] M N O
[6] P Q R
[7] S T U
[8] V W X
[9] Y Z
