7.2 Zone Definition Status
There are eight zone definitions that are affected by the Flex-Instant delay (section [720]). The following table shows how the
zone definition changes depending on the arm status and if the Flex-Instant delay is enabled. see Zone Definition Status on page
28.
7.3 Zone Partition Assignment
Sections [001] to [032]: Zones 1 to 32
The control panel provides the option of partitioning the security system into two completely independent systems. Sections [001]
to [032] represent zones 1 through 32 respectively, where the third digit in each of these sections represents the zone's partition
assignment. The zone is assigned to Partition 1 if third digit = 1, Partition 2 if third digit = 2, or both partitions is third digit = 3. For
more details, see Partitioning on page 55.
7.4 Zone Options
Sections [001] to [032] represent zones 1 through 32 respectively. After entering the definition and partition assignment, select
one or more of the following Zone Options by using the Multiple Feature Select Programming Method:
7.4.1 Auto Zone Shutdown
Sections [001] to [032] = Zones 1 to 32
Option [1] OFF = Auto Zone Shutdown Disabled
Option [1] ON = Auto Zone Shutdown Enabled for
selected zone (default)
If, in a single armed period, the number of alarms generated by a zone with the Auto Zone Shutdown option enabled
exceeds the number defined by the Auto Zone Shutdown Counter, the control panel will no longer generate an alarm
for that zone. To program the Auto Zone Shutdown Counter, key in the desired limit (000=Disabled, 001 to 015, Default
= 5) into section [712]. The Auto Zone Shutdown Counter resets every time a valid code is entered.
7.4.2 Bypassable Zones
Sections [001] to [032] = Zones 1 to 32
Option [2] OFF = Bypass Zone Disabled
Option [2] ON = Selected Zone is Bypass Enabled (default)
When a user utilizes the Bypass Programming feature (see Bypass Programming on page 22), only zones with the
Bypass option enabled can be programmed as bypassed.
Do not program a fire zone with the Bypass option, as the control panel will never bypass fire zones.
Zone Definitions Stay Arm Sleep Arm Fully Arm
01 = Entry Delay 1 Entry Delay 1 Entry Delay 1 Entry Delay 1
02 = Entry Delay 2 Entry Delay 2 Entry Delay 2 Entry Delay 2
03 = Entry Delay 1 (Full Arm)
Not Armed Not Armed Entry Delay 1
04 = Entry Delay 2 (Full Arm)
Not Armed Not Armed Entry Delay 2
05 = Follow Follow* Follow* Follow*
06 = Follow (Sleep/Full Arm) Not Armed Follow* Follow
07 = Follow (Full Arm)
Not Armed Not Armed Follow
08 = Instant Instant* Instant* Instant*
09 = Instant (Sleep/Full Arm) Not Armed Instant* Instant
10 = Instant (Full Arm)
Not Armed Not Armed Instant
23 = Instant No Pre-Alarm Instant Instant Instant*
24 = Follow No Pre-Alarm Follow Follow Follow*
* Flex-Instant = Zone will follow the delay at section [720], (default is 15 seconds / 0 = instant zone)
