Paradox Magellan MG5050 EN User Manual

Magellan / Spectra SP 1
1.4 Specifications
All control panel outputs are rated to operate between 10.8Vdc and 12.1Vdc
MG5000 / MG5050
Power rating 16.5 VAC (50 or 60Hz) minimum 20 VA (40 VA recommended)
Power consumption MG5000: 1.2A(Max.), 85mA (Idle) MG5050: 1.2A(Max.), 95mA (Idle)
Aux. power * 600 mA typical, 700 mA maximum, fuseless shutdown at 1.1A
Battery 12 VDC, 4Ah/7Ah
Battery charging current 350 mA
On-board zones MG5000: 2, MG5050: 5
Bell output ** 1A (fuseless shutdown at 3A)
On-board PGMs MG5000: 2
MG5050: 4 (1+/- trigger)
All on-board PGMS are 100mA low-current outputs
Dimensions MG5000: 14 x 10.4cm (5.5 x 4.1”)
MG5050: 19 x 10.2cm (7.5 x 4”)
Weight 18 g
Operating temperature 0°C to 50°C (32°F to 122°F)
Humidity 5% - 90%
* Cannot exceed 200 mA for UL installations
** Cannot exceed 1A for UL installations
SP4000 / SP5500 / SP6000 / SP65 / SP7000
Power rating 16.5Vac (50 or 60Hz) minimum 20VA (40VA recommended)
Power consumption SP4000: 1.2A(Max.), 50mA (Idle), SP5500: 1.2A(Max.), 70mA (Idle), SP65: 1.2A(Max.), 66mA (Idle)
SP6000: 1.7A(Max.), 100mA (Idle), SP7000: 1.7A(Max.), 120mA (Idle)
Aux. power SP4000: 450mA, fuseless shutdown at 600mA
SP65: 500mA, fuseless shutdown at 750mA
SP5500 / SP6000 / SP7000: 600mA typical,
700mA maximum, fuseless shutdown at 1.1A
Battery 12Vdc, 4Ah/7Ah
Battery charging current SP4000 / SP65: Limited by 1.1A supply current
(AUX consumption - no dedicated battery current
limit circuit)
SP5500: 350 mA
SP6000 / SP7000: 350 mA / 850 mA
On-board zones SP4000: 4
SP5500: 5
SP6000: 8
SP65: 9
SP7000: 16
Bell output 1A (fuseless shutdown at 3A)
On-board PGMs SP4000: 1
SP5500: 2
SP6000: 2+(2 optional) (all +/- trigger)
SP65: 3 (all +/- trigger)
SP7000: 4 (all +/- trigger)
All on-board PGMS are 100mA low-current outputs
Dimensions SP4000: 14 x 6.6cm (5.5 x 2.6”)
SP5500: 19 x 8.9cm (7.5 x 3.5”)
SP6000: 19 x 9cm (7.5 x 3.5”)
SP65: 14 x 6.6cm (5.5 x 2.6”)
SP7000: 20.3 x 10.8cm (8 x 4.25”)
Weight SP4000: 12 g
SP5500: 16 g
SP6000: 20 g
Operating temperature 0°C to 50°C (32°F to 122°F)
Humidity 5% - 90%
Standards EN 50131-1, EN 50131-3, EN 50131-6 Type A, Security Grade 2
Environmental Class II/ Certification Body: Intertek
30hrs backup 60hrs backup Recharge to 80%(@350mA)
7AHr 150mA 50mA 20 hrs.
