Magellan / Spectra SP 47
Option [3] ON = Clear arm/disarm/alarm reporting codes (default)
Option [4] OFF = Clear trouble reporting codes
Option [4] ON = Clear trouble reporting codes (default)
Enable all options you want to clear. The respective sets of reporting codes will be cleared after exiting the section.
12.10 Reset Reporting Codes
Section [967]: Reset Reporting Codes
Option [1] OFF = Reset zone reporting codes
Option [1] ON = Reset zone reporting codes (default)
Option [2] OFF = Reset user reporting codes
Option [2] ON = Reset user reporting codes (default)
Option [3] OFF = Reset arm/disarm/alarm reporting codes
Option [3] ON = Reset arm/disarm/alarm reporting codes (default)
Option [4] OFF = Reset trouble reporting codes
Option [4] ON = Reset trouble reporting codes (default)
Enable all options you want to reset to default. The respective sets of reporting codes will be reset after exiting the section.
12.11 Monitoring Station Telephone Numbers
Section [815] = Phone#1, [816] = Phone#2, [817] = Backup Phone#, [818] = Pager #, [819] = Numeric
Message Sent with Pager Reporting: Up to 32 digits
The control panel can dial up to 2 different monitoring station telephone numbers. You can enter any digit from 0 to 9 and any
special keys or functions (see Table 5 on page 47) up to a maximum of 32 digits. After the maximum dialing attempts (see
Maximum Dialing Attempts on page 49) to one monitoring station telephone number have failed, the control panel will then dial
the backup telephone number. If the Alternate Dial Option (see Alternate Dial Option on page 49) is enabled, the control panel will
dial the programmed backup telephone number after every failed attempt. If no backup telephone number is programmed, the
control panel will never report to the backup telephone number. Also see Delay Between Dialing Attempts on page 49.
12.12 Personal Dialing Numbers
Personal Dialing numbers are personal numbers (e.g. cellular, office) that the panel can call in case of an alarm or panic. To
program these five numbers see the Communicator Menu in either the Master or User Quick Menu. To set the call parameters,
see options [5], [6], and [7] of section [804].
The panel will call these personal numbers if programmed in the event of any panic or alarm (default) and sound a bell tone. To
program the delay between the call attempts, see section [832]. The panel can also be programmed to delay before sounding the
bell tone, which can be programmed in section [836].
The default delay is 20 seconds. To determine the length of time the bell tone sounds on the phone line, see section [837]. The
default value is 003, meaning the 10 second bell tone will repeat itself 3 times after the initial sequence (total= 40 seconds).
12.13 Reporting Formats
Section [810]: 1st digit = Format for Phone #1, 2nd digit = Format for Phone #2
The panel can use a number of different reporting formats and each monitoring station telephone number can be programmed
with a different reporting format. The first digit entered into section [810] represents the reporting format used to communicate
with Monitoring Station Telephone Number 1, the second digit represents the reporting format used to communicate with
Monitoring Station Telephone Number 2. The Backup Telephone Number uses the same reporting format as the last monitoring
station telephone number that was dialed.
Table 5: Special Keys for Telephone Numbers
Press Action or Value
[
OFF] *
[BYP] #
[
MEM] switch from pulse to tone dialing or vice versa
[
TBL] 4-second pause
[SLEEP] deletes current digit
[] inserts blank space
