12 Reference & Installation Manual
4.3.1 Assign a User to the MG-RCV3 (Esprit mode only)
SECTIONS [01] TO [08]
When a user presses a remote control’s button, the MG-RCV3
transmits the corresponding user code to the Esprit control panel. The
control panel must receive a valid user code in order to process the
action. Sections [01] to [08] represent users 1 to 8 respectively (refer to
Table 4.1 on page 11).
The user code entered in sections [01] to [08] must match the
same user’s code programmed in the Esprit control panel.
4.3.2 Assign a Remote Control
SECTIONS [09] TO [16]
When connected to an Esprit control panel, assign up to eight Omnia
remote controls to users in the Esprit security system, whereby
sections [09] to [16] correspond to users 1 to 8 respectively (refer to
Table 4.1 on page 11). Each time a remote control’s button is pressed, it
transmits its RF code to the MG-RCV3, which contains the
corresponding user information. In stand-alone mode, assign up to
eight remote controls to the module, whereby sections [09] to [16]
represent remote controls 1 to 8 (refer to Table 4.1 on page 11).
How to assign a user to the MG-RCV3.
In step 4 in section 3.2 on page 10:
1. Enter a section number between [01] and [08].
2. Enter the [
USER CODE].
3. Press [
ENTER].
How to assign a remote control.
In step 4 in section 3.2 on page 10:
1. Enter a section number between [09] and [16].
2. Press [
ENTER]. The keypad’s “Ready” and “Arm” lights will
illuminate.
3. Press and hold any button on the remote control until the keypad
beeps twice to confirm. If the keypad doesn’t beep, repeat the
step until it does.
4. Press [
ENTER].
