Magellan Wireless Expansion Module 1
1.0 Introduction
This manual details how to connect, program and operate the Magellan wireless
expansion module (MG-RCV3) when used in conjunction with an Esprit security
system or as a stand-alone system.
When connected to an Esprit security system, the MG-RCV3 functions as an arm/
disarm module, whereby up to eight Magellan remote controls (MG-REM1) can
perform actions such as remote arming and disarming, communicating panic alarms
and activating programmable outputs (PGMs). In stand-alone mode, the remote
controls will only activate the four on-board PGMs.
1.1 Technical Specifications
• Di-pole antenna
• Error Correction Algorithm
• Compatibility Any Magellan wireless transmitter
• Frequency: 433MHz or 868MHz
• Range (line of sight): Remote controls = 100m (300ft)
• Sensitivity: -120 dBm
• Current consumption: 50 mA
• Dimensions (no antenna): 15cm H x 16cm L x 3cm W
(6in H x 6.5in L x 1.1in W)
• Operating temperature: 0°C to 49°C (32°F to 120°F)
• PGM outputs: 4 on-board PGM outputs:
PGM1 and PGM2 - 150mA PGM
transistor outputs
PGM3 - form C relay output rated
at 5A/28Vdc, N.O./N.C. (PGM4
optional)
• Programming keypad: Esprit 636 or 646 LED keypad
