42 Programming Guide
Trouble Display
Press the [TBL] key to view the Trouble Display. Please note that the keypad can be programmed to emit a BEEP every 5 seconds
whenever a new trouble condition has occurred. Press the [
TBL] key to stop the beeping.
To view the sub-menu, press the corresponding key in the main menu.
Main Menu Trouble Sub-Menu Trouble Menu
[1] Wireless zone low battery [1] to [32] Zones in low battery
[2] Power trouble [1] Low/No battery on the control panel
[2] AC failure on control panel
[3] Auxiliary overload on control panel
[4] Wireless keypad AC failure
[5] Wireless keypad battery failure
[6] Wireless repeater AC failure
[7] Wireless repeater battery failure
[8] Wireless siren AC failure
[9] Wireless siren battery failure
[3] Bell trouble [1] Bell disconnect on control panel
[2] Bell overload on control panel
[4] Communication trouble [1] Telephone Line Monitoring on control panel
[2] Fail to communicate on Monitoring Telephone 1 on control panel
[3] Fail to communicate on Monitoring Telephone 2 on control panel
[5] Fail to communicate on voice telephone on control panel
[6] Fail to communicate with PC on control panel
[7] Fail to communicate with IP receiver 1 or 2 (GPRS)
[8] Fail to communicate with IP receiver 1 or 2 (IP)
[9] GSM no service (GSM network failure)
[10] IP Module No Service (network failure)
[
STAY] GSM RF jamming
[OFF] IP Receiver Unregistered (IP/GPRS)
[5] Tamper and zone wiring failure [1] to [32] Zones in tamper and zone wiring failure
[6] Module tamper trouble [1] 2WPGM
[2] Keypad bus
[3] ZX8 bus module
[4] RTX3 bus module
[5] Wireless siren
[7] Fire loop trouble [1] to [32] Zones in fire loop trouble
[8] Timer loss
[9] Wireless zone supervision loss [1] to [32] Zones in supervision lost
[
STAY] RF jamming trouble
[0 (10)] or [10] Module supervision loss [1] 2WPGM
[2] Keypad bus (Panel reset will not clear this trouble, clear it in section [955])
[3] ZX8 bus module
[4] RTX3 bus module
[5] Wireless keypad
[6] Wireless repeater
[7] N/A
[8] VDMP3
[9] PCS Series (GPRS)
[10] IP100
[
STAY] Wireless siren
[16] Keypad fault (K32 / K32RF / K37 / K35 only)
[17] Upgrade panel to V3.2 or higher (K37 only)
[
SLEEP] Keypad fault (K636 / K10V/H only)
