Paradox Spectra SP4000 Programming Guide

18 Programming Guide
Zone Report Codes (Default = FF)
Keypad Programming
Keypad Zone Number Assignment
Entry Point Zone Assignment (StayD)
Keypad Input/Output Configuration (K636 V2.0 and higher)
NOTE: When configuring as an output, you must first clear the keypad zone (if assigned).
[966] Clear Zone Report Codes
Option OFF ON
[1] Clear zone report codes*
 Disabled

Enabled
* Ensure all other options are deselected. Press [
ENTER] to clear the respective set of report codes before exiting the section.
[967] Reset Zone Report Codes
Option OFF ON
[1] Reset zone report codes to default*
 Disabled

Enabled
* Ensure all other options are deselected. Press [
ENTER] to reset the respective set of report codes before exiting the section.
Section Alarm
Alarm
Restore
Tamper
Tamper
Restore
Section Alarm
Alarm
Restore
Tamper
Tamper
Restore
[141] Zone 1: ___/___ ___/___ ___/___ ___/___ [157] Zone 17: ___/___ ___/___ ___/___ ___/___
[142] Zone 2: ___/___ ___/___ ___/___ ___/___ [158] Zone 18: ___/___ ___/___ ___/___ ___/___
[143] Zone 3: ___/___ ___/___ ___/___ ___/___ [159] Zone 19: ___/___ ___/___ ___/___ ___/___
[144] Zone 4: ___/___ ___/___ ___/___ ___/___ [160] Zone 20: ___/___ ___/___ ___/___ ___/___
[145] Zone 5: ___/___ ___/___ ___/___ ___/___ [161] Zone 21: ___/___ ___/___ ___/___ ___/___
[146] Zone 6: ___/___ ___/___ ___/___ ___/___ [162] Zone 22: ___/___ ___/___ ___/___ ___/___
[147] Zone 7: ___/___ ___/___ ___/___ ___/___ [163] Zone 23: ___/___ ___/___ ___/___ ___/___
[148] Zone 8: ___/___ ___/___ ___/___ ___/___ [164] Zone 24: ___/___ ___/___ ___/___ ___/___
[149] Zone 9: ___/___ ___/___ ___/___ ___/___ [165] Zone 25: ___/___ ___/___ ___/___ ___/___
[150] Zone 10: ___/___ ___/___ ___/___ ___/___ [166] Zone 26: ___/___ ___/___ ___/___ ___/___
[151] Zone 11: ___/___ ___/___ ___/___ ___/___ [167] Zone 27: ___/___ ___/___ ___/___ ___/___
[152] Zone 12: ___/___ ___/___ ___/___ ___/___ [168] Zone 28: ___/___ ___/___ ___/___ ___/___
[153] Zone 13: ___/___ ___/___ ___/___ ___/___ [169] Zone 29: ___/___ ___/___ ___/___ ___/___
[154] Zone 14: ___/___ ___/___ ___/___ ___/___ [170] Zone 30: ___/___ ___/___ ___/___ ___/___
[155] Zone 15: ___/___ ___/___ ___/___ ___/___ [171] Zone 31: ___/___ ___/___ ___/___ ___/___
[156] Zone 16: ___/___ ___/___ ___/___ ___/___ [172] Zone 32: ___/___ ___/___ ___/___ ___/___
Step Action Details
1 [
ENTER] + [INSTALLER CODE]
(default: 0000 / 000000)
[ARM] + [STAY] = flash. [MAINTENANCE CODE] may also be used.
2
Press and hold (3sec)
[ARM] + [STAY] = on.
3 [
ZONE NUMBER] + [ENTER] K35 / K32 / K32LCD = 2 digits: 01 to 32.
K636 / K10V/H = 1 digit: 1 to 0 (10).
To erase a keypad zone number, press [
CLEAR], then [ENTER].
Step Action Details
1 [ENTER] + [INSTALLER CODE]
(default: 0000 / 000000)
[ARM] + [STAY] = flash.
2 Press and hold [OFF] (3sec) [ARM] + [STAY] = on.
3 [ZONE NUMBER] K35 / K32RF / K37 / K32 / K32LCD = 2 digits: 01 to 32.
K636 / K10V/H = 1 digit: 1 to 0(10) (maximum 10 zones).
The first zone you program will be the designated entry point and will flash. Up to three more
path zones can be added; these zones will light up and stay lit.
4 [
ENTER] Press [ENTER] to save and exit.
Step Action Details
1 [
ENTER] + [INSTALLER CODE]
(default: 0000 / 000000)
[ARM] + [STAY] = flash.
2 Press and hold [ENTER] (3sec) [ARM] + [STAY] = on.
3Option [1] ON = Output switches to ground following system arming (Blue wire 150mA max.).
OFF = Input (Keypad zone input).
4Option [2] ON = Output N.C. OFF = Output N.O.

Paradox Spectra SP4000 Specifications

General

Partitions	2
User Codes	32
Event Buffer	256 events
StayD Mode	Yes
Expandable via Expansion Modules	Yes
Bus	Yes, 4-wire expansion bus
Battery Backup	12V 7Ah
PGM Outputs	2
