Paradox Spectra SP4000

Magellan / Spectra SP 5
Specifications
Entering Programming Mode
WARNING: StayD Mode must be deactivated in order to enter programming mode. To deactivate StayD, press [OFF] + [MASTER /
USER CODE] + [OFF].
1. Press [
ENTER].
2. Enter your [
INSTALLER CODE] (default: 000000) or [MAINTENANCE CODE] (no default). [ARM] and [STAY] lights flash.
To modify codes, see System Codes on page 50.
3. Enter the 3-digit [
SECTION] you wish to program ([ARM] and [STAY] lights are ON).
4. Enter required [
DATA].
MG5000 / MG5050
Power rating 16.5 VAC (50 or 60Hz) minimum 20 VA (40 VA recommended)
Aux. power 600 mA typical, 700 mA maximum, fuseless shutdown at 1.1A
Battery 12 VDC, 4Ah/7Ah
Battery charging current 350 mA
On-board zones MG5000: 2
MG5050: 5
Bell output 1A (fuseless shutdown at 3A)
On-board PGMs MG5000: 2
MG5050: 4 (1+/- trigger)
All on-board PGMS are 100mA low-current outputs
Dimensions MG5000: 14 x 10.4cm (5.5 x 4.1”)
MG5050: 19 x 10.2cm (7.5 x 4”)
Operating temperature 0°C to 50°C (32°F to 122°F)
SP4000 / SP5500 / SP6000 / SP7000
Power rating 16.5Vac (50 or 60Hz) minimum 20VA (40VA recommended)
Aux. power SP4000:
450mA, fuseless shutdown at 650mA
SP5500 / SP6000 / SP7000:
600mA typical, 700mA maximum,
fuseless shutdown at 1.1A
Battery 12Vdc, 4Ah/7Ah
Battery charging current SP4000: Limited by 1.1A supply current
(AUX consumption - no dedicated
battery current limit circuit)
SP5500: 350 mA
SP6000 / SP7000: 350 mA / 850 mA
On-board zones SP4000: 4
SP5500: 5
SP6000: 8
SP7000: 16
Bell output 1A (fuseless shutdown at 3A)
On-board PGMs SP4000: 1
SP5500: 2 (all +/- trigger)
SP6000: 2+(2 optional) (all +/- trigger)
SP7000: 4 (all +/- trigger)
All on-board PGMS are 100mA low-current outputs
Dimensions SP4000: 14 x 6.6cm (5.5 x 2.6”)
SP5500: 19 x 8.9cm (7.5 x 3.5”)
SP6000: 19 x 8.9cm (7.5 x 3.5”)
SP7000: 20.3 x 10.8cm (8 x 4.25”)
Operating temperature 0°C to 50°C (32°F to 122°F)
