Magellan / Spectra SP 39
Ademco Contact ID Report Codes
CID# Reporting Code Value CID# Reporting Code Value CID# Reporting Code Value
Medical Alarms - 100 321 Bell 1 48 429 Access program mode entry 91
100 Medical alarm 01 322 Bell 2 49 430 Access program mode exit 92
101 Pendant transmitter 02 323 Alarm relay 4A 431 Access threat level change 93
102 Fail to report in 03
324 Trouble relay 4B 432 Access relay/trigger fail 94
Fire Alarms - 110 325 Reversing relay 4C 433 Access RTE shunt 95
110 Fire alarm 04 326 Notification appliance chk. #3 4D 434 Access DSM shunt 96
111 Smoke 05
327 Notification appliance chk. #4 4E Arming - 440 and 450
112 Combustion 06
System Peripheral Troubles - 330 and 340 441 Armed Stay 97
113 Water flow 07 330 System peripheral 4F 442 Keyswitch armed Stay 98
114 Heat 08 331 Polling loop open 50 450 Exception open/close 99
115 Pull station 09
332 Polling loop short 51 451 Early open/close 9A
116 Duct 0A
333 Expansion module failure 52 452 Late open/close 9B
117 Flame 0B 334 Repeater failure 53 453 Failed to open 9C
118 Near alarm 0C 335 Local printer paper out 54 454 Failed to close 9D
Panic Alarms - 120 336 Local printer failure 55 455 Auto-arm failed 9E
120 Panic Alarm 0D 337 Exp. module DC loss 56 456 Partial arm 9F
121 Duress 0E 338 Exp. module low battery 57 457 Exit error (user) A0
122 Silent 0F 339 Exp. module reset 58 458 User on premises A1
123 Audible 10 341 Exp. module tamper 59 459 Recent close A2
124 Duress - Access grated 11 342 Exp. module AC loss 5A System - 460
125 Duress - Egress granted 12 343 Exp. module self-test fail 5B 461 Wrong code entry A3
Burglar Alarms - 130 344 RF receiver jam detect 5C 462 Legal code entry A4
130 Burglary 13 Communication Troubles - 350 and 360 463 Re-arm after alarm A5
131 Perimeter 14 350 Communication 5D 464 Auto-arm time extended A6
132 Interior 15 351 Telco 1 fault 5E 465 Panic alarm reset A7
133 24-hour 16 352 Telco 2 fault 5F 466 Service ON/OFF premises A8
134 Entry/Exit 17 353 Long range radio 60 Sounder Relay Disabled - 520
135 Day/Night 18 354 Fail to communicate 61 520 Sounder/Relay disabled A9
136 Outdoor 19 355 Loss of radio supervision 62 521 Bell 1 disabled AA
137 Ta mpe r 1A 356 Loss of central polling 63 522 Bell 2 disabled AB
138 Near alarm 1B 357 Long range radio VSWR prob. 64 523 Alarm relay disabled AC
139 Intrusion verified 1C Protection Loop Troubles - 370 524 Trouble relay disabled AD
General Alarms - 140 370 Protection loop 65 525 Reversing relay disabled AE
140 General alarm 1D 371 Protection loop open 66 526 Notification appliance chk.#3 disabled AF
141 Polling loop open 1E 372 Protection loop short 67 527 Notification appliance chk.#4 disabled B0
142 Polling loop short 1F 373 Fire trouble 68 Modules - 530
143 Expansion module failure 20 374 Exit error alarm 69 531 Module added B1
144 Sensor tamper 21 375 Panic zone trouble 6A 532 Module removed B2
145 Expansion module tamper 22 376 Hold-up zone trouble 6B Communication Disables - 550 and 560
146 Silent burglary 23 377 Swinger trouble 6C 551 Dialer disabled B3
147 Sensor supervision failure 24 378 Cross-zone trouble 6D 552 Radio transmitter disabled B4
24-hour Non-burglary - 150 and 160 Sensor Troubles - 380 and 390 Bypasses - 570
150 24-hour non-burglary 25 380 Sensor trouble 6E 570 Zone bypass B5
151 Gas detected 26 381 Loss of supervision - RF 6F 571 Fire bypass B6
152 Refrigeration 27 382 Loss of supervision - RPM 70 572 24Hr. zone bypass B7
153 Loss of heat 28 383 Sensor tamper 71 573 Burglary bypass B8
154 Water leakage 29 384 RF transmitter low battery 72 574 Group bypass B9
155 Foil break 2A 385 Smoke detector Hi sensitivity 73 575 Swinger bypass BA
156 Day trouble 2B 386 Smoke detector Low sensitivity 74 576 Access zone shunt BB
157 Low bottled gas level 2C 387 Intrusion detector Hi sensitivity 75 577 Access point bypass BC
158 High temperature 2D 388 Intrusion detector Low sensitivity 76
Test/Misc. - 600
159 Low temperature 2E 389 Sensor self-test failure 77 601 Manual trigger test BD
161 Loss of air flow 2F 391 Sensor watch trouble 78 602 Periodic test report BE
162 Carbon monoxide detected 30 392 Drift compensation error 79 603 Periodic RF transmission BF
163 Tank level 31 393 Maintenance alert 7A 604 Fire test C0
Fire Supervisory - 200 and 210 Open/Close - 400 605 Status report to follow C1
200 Fire supervisory 32 400 Open/Close 7B 606 Listen-in to follow C2
201 Low water pressure 33 401 Open/Close by user 7C 607 Walk test mode C3
202
Low CO
2
34 402 Group open/close 7D 608 Periodic test - system trouble present C4
203 Gate valve sensor 35 403 Automatic open/close 7E 609 Video transmitter active C5
204 Low water level 36 406 Cancel 7F 611 Point test OK C6
205 Pump activated 37 407 Remote arm/disarm 80 612 Point not tested C7
206 Pump failure 38 408 Quick arm 81 613 Intrusion zone walk tested C8
System Troubles - 300 and 310 409 Keyswitch open/close 82 614 Fire zone walk tested C9
300 System trouble 39
Remote Access - 410 615 Panic zone walk tested CA
301 AC loss 3A 411 Call back request made 83 616 Service request CB
302 Low system battery 3B 412 Success - download access 84 621 Event log reset CC
303 RAM checksum bad 3C 413 Unsuccessful access 85 622 Event log 50% full CD
304 ROM checksum 3D 414 System shutdown 86 623 Event log 90% full CE
305 System reset 3E 415 Dialer shutdown 87 624 Event log overflow CF
306 Panel program changed 3F 416 Successful upload 88 625 Time/Date reset D0
307 Self-test failure 40 Access Control - 420 and 430 626 Time/Date inaccurate D1
308 System shutdown 41 421 Access denied 89 627 Program mode entry D2
309 Battery test failure 42 422 Access report by user 8A 628 Program mode exit D3
310 Ground fault 43 423 Forced access 8B 629 32-hour event log marker D4
311 Battery missing/dead 44 424 Egress denied 8C 630 Schedule change D5
312 Power supply over current limit 45 425 Egress granted 8D 631 Exception schedule change D6
313 Engineer reset 46 426 Access door propped open 8E 632 Access schedule change D7
Sounder/Relay Troubles - 320 427 Access point door status monitor trouble 8F 654 System inactivity D8
320 Sounder/relay 47 428 Access point request to exit 90
