Magellan / Spectra SP 29
Programmable Output Programming
Programmable Output Recognition
* A wireless PGM module can be assigned to any PGM. It will work in parallel with the control panel output (does not apply to SP4000
systems).
PGM Labels
NOTE: For label character tables, see LCD Keypad Labels (K32LCD) on page 47.
Programmable Output Activation/Deactivation Events
PGM Output SP4000 SP5500* SP6000* SP7000* MG5000* MG5050*
PGM 1 Control panel output 1
PGM 2 Control panel output 2 N/A
PGM 3 Control panel output 3 N/A N/A Optional N/A
PGM 4 Control panel output 4 N/A N/A Optional N/A
PGM 5 Control panel relay N/A N/A Optional N/A N/A
PGM 6 ZX8 ID= 1 output
PGM 7 ZX8 ID= 2 output
PGM 8 ZX8 ID= 3 output N/A
PGM 9 PGM4 relay 1
PGM 10 PGM4 relay 2
PGM 11 PGM4 relay 3
PGM 12 PGM4 relay 4
PGM 13 RTX3/RX1 output 1
PGM 14 RTX3/RX1 output 2
PGM 15 RTX3 output 3 (relay)
PGM 16 RTX3 output 4 (relay)
[965] Reset PGM Labels
Option OFF ON
[4] Reset PGM labels*
Disabled
Enabled
* Ensure all other options are deselected. Press [
ENTER] to reset the respective set of labels to default before exiting the section.
Section PGM Label Section PGM Label
[341] 1 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__ [349] 9 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[342] 2 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__ [350] 10 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[343] 3 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__ [351] 11 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[344] 4 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__ [352] 12 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[345] 5 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__ [353] 13 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[346] 6 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__ [354] 14 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[347] 7 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__ [355] 15 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[348] 8 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__ [356] 16 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
Section Event Group # Sub-Group #
Partition # (99 for
both partitions)
Default
[220] PGM 1: Activation Event (____/____) (____/____) (____/____) 08/99/99*
[221] Deactivation Event (____/____) (____/____) (____/____) 00/00/00
[222] PGM 2: Activation Event (____/____) (____/____) (____/____) 09/99/99†
[223] Deactivation Event (____/____) (____/____) (____/____) 00/00/00
[224] PGM 3: Activation Event (____/____) (____/____) (____/____) 00/00/00
[225] Deactivation Event (____/____) (____/____) (____/____) 00/00/00
[226] PGM 4: Activation Event (____/____) (____/____) (____/____) 00/00/00
[227] Deactivation Event (____/____) (____/____) (____/____) 00/00/00
[228] PGM 5: Activation Event (____/____) (____/____) (____/____) 00/00/00
[229] Deactivation Event (____/____) (____/____) (____/____) 00/00/00
[230] PGM 6: Activation Event (____/____) (____/____) (____/____) 00/00/00
[231] Deactivation Event (____/____) (____/____) (____/____) 00/00/00
[232] PGM 7: Activation Event (____/____) (____/____) (____/____) 00/00/00
[233] Deactivation Event (____/____) (____/____) (____/____) 00/00/00
[234] PGM 8: Activation Event (____/____) (____/____) (____/____) 00/00/00
[235] Deactivation Event (____/____) (____/____) (____/____) 00/00/00
See Quick Menus on page 65
